- Page 1 Kongskilde - Polska Spółka z o.o. ul. Metalowa 15, 99-300 Kutno, Poland phone: (024) 355 15 15, fax: (024) 355 15 35 E-mail: mail@kpl.kongskilde.com VIBRO MASTER Manual Catalogue of spare parts SEEDBEDCULTIVATOR. “VIBRO MASTER” 2016, Edition 2...
-
Page 2: Table Of Contents
CONTENTS page CONTENTS _________________________________________________________________ 2 1. General information _________________________________________________________ 3 2. Rules on Safe Work _________________________________________________________ 4 3. Intended use _______________________________________________________________ 5 4. Construction and work of the cultivator _________________________________________ 5 4.1. Hydraulic system ______________________________________________________________ 6 5. Equipment _________________________________________________________________ 7 6. -
Page 3: General Information
KONGSKILDE-POLSKA Spółka z o.o., or a point of sale of the machine. The company: KONGSKILDE - POLSKA IS ALWAYS READY TO HELP USERS OF OUR EQUIPMENT BY ADVISING AND BY MEANS OF TECHNICAL ASSISTANCE PROVIDED BY HIGHLY QUALI- FIED STAFF MEMBERS. -
Page 4: Rules On Safe Work
2. Rules on Safe Work NOTE! - in order to avoid danger, before commencement of work with the cultiva- tor, it is necessary to become familiarised with contents of this manual and to comply with the following guidelines: Operation and exploitation of the cultivator may be entrusted only to a person who has ap- propriate qualifications entitling to work with tractor agricultural cultivators and who has be- come familiarised with this manual. -
Page 5: Intended Use
NOTE! - A failure to comply with the foregoing rules may lead to dangers for an operator and outsiders as well as to damage of the cultivator. For damage arising from this reason KONGSKILDE-Poland shall not be liable. 3. Intended use. The seedbed cultivator U646/3 “VIBRO MASTER” is intended for pre-sowing cultivation of soil on fields after earlier ploughing. -
Page 6: Hydraulic System
is fixed by means of spring clamp. Segmental construction of the slat makes it possible to match it precisely to any possible unevenness of land. Spring scarifying tines of the SQ type are universal and may be used in the entire range of con- ditions of light and average soils. -
Page 7: Equipment
646-Io/I/98 5. Equipment. In a standard version the cultivator is equipped with: spring tines of the SQ type with reversible coulters, supporting wheels 165x15, beam of the quick coupler, rubber shock-absorber, hydraulic installation for folding side frames, ... -
Page 8: Connection Of The Cultivator With A Tractor
6.2. Connection of the cultivator with a tractor. NOTE! - The machine has to be coupled with a tractor on horizontal and even surface. In order to connect the cultivator with a tractor it is necessary: to put a beam of the quick coupler on couplers of the jack in a tractor (Fig. -
Page 9: Preparation Of The Cultivator For Work
646-Io/I/98 connect the hydraulic ducts of the cultivator with sockets of external hydraulics on a tractor. After disconnection of the cultivator, the activities have to be carried out in reverse order. Re- lease of the beam of the quick coupler takes place after pulling away the left and right arms of the spring catch. -
Page 10: Work With The Cultivator
6.4. WORK WITH THE CULTIVATOR. In order to correctly perform work with the cultivator it is necessary to comply with the following rules: make sure that working units of the seedbed cultivator are in working order, rollers rotate without interruptions, tines are not bent and their coulters are properly sharp, ... -
Page 11: Storage Of The Cultivator
646-Io/I/98 The activities have to be carried out after turning off the engine in a tractor and pulling the hand brake. After replacement of the tine, the fastening screws have to be tightened up with 90 Nm moment. NOTE! - going under the cultivator during operation and reparation works is not allowed and may result in serious injury of the body. -
Page 12: Disassembly
9. Disassembly. Disassembly of the cultivator should be carried out by persons earlier familiarised with its con- struction. These activities need to be carried out after placing the cultivator in working position (unfolded side arms) on even and hard bed. In view of the scale of forces which may exceed 200 N, during disassembly of particular components (side arms, main frame, road wheels etc.) it is necessary to use lifting equipment. -
Page 13: Warning And Informative Graphics
NOTE! TIGHTEN UP ALL SCREWS AFTER THE On side supports of the sus- FIRST HOUR OF WORK. pension system Trademark Kongskilde and inscription VIBRO MASTER At the back and in front on the frame REMEMBER - In case of destruction of or illegible entries, it is necessary to replace them. -
Page 14: Technical Characteristics Of The Cultivator
12. Technical characteristics of the cultivator. Table 2. Technical characteristics of the cultivator „VIBRO MASTER”, type „SGC” and „SQ”: Specification Unit Value meas Symbol 4.3 m 4.7 m 4.9 m 5.3 m 5.9 m 6.3 m 6.7 m Dimensions in transport position ... -
Page 15: Notes
646-Io/I/98 NOTES... - Page 16 101 000 793 01-2016...
