  • Page 1 VIBRO MASTER 3000 Directions for use...
  • Page 2: Table Of Contents

    Folding and unfolding with mechanical wing lock system.......15 Folding and unfolding with automatic wing lock system........16 Preparing for road transport ................ 16 Adjustment and use of Vibro Master 3000 ............. 17 Adjustment of the cultivator working depth ..........17 Adjustment of the level board ............... 18 Adjustment of the rear rollers (parallelogram) ..........
  • Page 3: Introduction

    Master 3000! Identification The specifications of the Vibro Master 3000 can be found in the type plate. This is located on the left side of the head stock, as shown on the below drawing. Please note the specifications from the type plate:...
  • Page 4: Explanation Of Symbols

    The serial number for the specific implement. For any queries regarding Vibro Master 3000 and for ordering spare parts, please quote the above specifications. The numbers for the spare parts can be found in the spare parts list supplied along with this users manual.
  • Page 5: Safety

    Vibro Master 3000 resulting from failure to apply safety advice. − The Vibro Master 3000 should only be used, maintained and repaired by persons, who are familiar with the safety advice and who are informed about the dangers.
  • Page 6: Three Point Hitch Or Linkage

    Vibro Master 3000 or in the danger zone of foldable parts without keeping a safe distance. − It is prohibited to allow any person to ride on the Vibro Master 3000. − Never work diagonally to inclines or slopes, where there is a risk that the tractor can tilt.
  • Page 7: Before Driving

    Suit your driving according to the conditions of the street. Pay special attention to the centre of gravity of hydraulic foldable machines. Do not exceed a speed of 25 km/h when transporting Vibro Master 3000 on the road. Before driving −...
  • Page 8: Maintenance

    − For maintenance on a raised up implement, always secure the Vibro Master 3000 on suitable stands. − Do not ever go under the Vibro Master 3000 unless secured on suitable stands. − Never attempt to disconnect hydraulic connections while system is pressurised.
  • Page 9: Safety Decals

    Moving Parts Do not stand near foldable frame of the Vibro Master 3000. Part no.: 71 000 629 546 Park in lowered position. The Vibro Master 3000 must ONLY be parked in working position. Part no.: 71 000 646 708...
  • Page 10 Always keep safety decals in clean and readable condition! Request substitutes for damaged or missing decals from the dealer and place these at the intended positions!
  • Page 11: Technical Data And Dimensions

    Technical data and dimensions Type VM 3065 VM 3075 VM 3083 Working width 6,5 m 7,5 m 8,3 m Transport width 3,0 m 3,0 m 3,0 m Transport height *) 3.19 m 3.69 m 4.09 m Hydr. folding Weights, kg Cultivator 1475 1725...
  • Page 12: Lifting Points

    • Always move the cultivator in unfolded position. • Do not stay under the cultivator when lifting Lifting the Vibro Master 3000 (with and without rear rollers connected) : • Fasten one connection in the pin for the top link connection...
  • Page 13: Operation

    Vibro Master 3000 can be connected by category 2 + 3. If they do not correspond, the three-point linkage on the tractor must be adjusted. Make sure that the Vibro Master 3000 is parked on solid ground and secure it against rolling.
  • Page 14: Uncoupling

    Uncoupling − Unfold the Vibro Master 3000 − Park the Vibro Master 3000 on levelled, solid ground. − Remove the oil pressure from the connections − Uncouple the hydraulic hoses from the tractor − Disconnect the light equipment (Optional) − Remove top link from the Vibro Master 3000 −...
  • Page 15: Folding And Unfolding With Mechanical Wing Lock System

    In this case operate the tractors hydraulic valve as to fold the implement and then pull the strings. − Use the hydraulics to unfold the Vibro Master 3000. Folding: − Make sure the strings for the security hooks are loose, so the security hooks are in the lower position ready to lock the wings when folded up −...
  • Page 16: Folding And Unfolding With Automatic Wing Lock System

    − Make sure the security hooks have locked the frames in upright position Folding and unfolding (automatic hydr. wing lock system) Vibro Master 3000 can be equipped with an automatic wing lock system. Micro cylinders are used instead of a string and work together with folding system for the side wings.
  • Page 17: Adjustment And Use Of Vibro Master 3000

    Adjustment and use of the Vibro Master 3000 The Vibro Master 3000 can be equipped with 4 different types of tines. See table below for recommended settings and use. Type of tine Working depth Working Tine distance Conditions speed Vibro S 4 –...
  • Page 18: Adjustment Of The Level Board

    The spikes on the level board are possible to mount in 2 height positions. From the factory the spikes are mounted in the upper hole. When the spikes get worn they must be moved to the lower hole. When worn out – replace with original Kongskilde spikes.
  • Page 19: Adjustment Of The Rear Rollers (Parallelogram)

    Position 1 : New spikes (upper hole) Position 2 : Worn spikes (lower hole) The level board is made for crushing and levelling – not for dozing big amounts of soil! Adjustment of the rear rollers The rear rollers are attached to the cultivator by a arm, which follows the soil during work and ensures optimal reconsolidation.
  • Page 20 Minimum pressure on the rollers Maximum pressure on the rollers Adjustment of the angle on the double rollers: The attack angle of the rollers can be adjusted. It is important to adjust this according to the soil conditions. The front roller must be set higher than the rear roller (app.
  • Page 21: Adjustment Of The Long Finger Rear Harrow

    Recommendation: • Pos. 1: for 4 - 6 cm working depth • Pos. 2: for 6 - 8 cm working depth • Pos. 3: for 8 – 10 cm working depth • Pos. 4: for 10 – 12 cm working depth Pos.
  • Page 22: Turning

    Maintenance General The KONGSKILDE Vibro Master 3000 needs very little maintenance: − After usage clean the machine. − All nuts and bolts must be checked and tightened after initial 10 working hours and then for every 100 hours.
  • Page 23: Lubrication

    Lubrication Hydraulic hoses and couplings Before every use of the Vibro Master 3000, check the hydraulic hoses and conections. If there is any sign of breakage emerging, make sure to change the parts in question. Note that if the hydraulic fails during folding or unfolding, then the wings...
  • Page 24: Warehousing And Storage

    Warehousing and storage For longer operation pauses, store the machine in safe place-not accessible for children. Prior to longer operation pauses (winter) and prior to first operation all lubrication points must be lubricated and pins and adjusting devices must be greased. During longer operation pauses exposed surfaces of tines, scrapers and rollers must be greased in order to prevent the formation of rust.
  • Page 25 300275300 01.02.2011...
