Gronomics RPB 18-48 Assembly Instruction

1
Parts Identifi cation
Stack matching pieces in piles. Using the parts list,
locate and count the individual pieces and verify that
you have received the correct number of pieces.
If any pieces are missing or replacement parts are
required, contact Gronomics at 1-855-299-6727.
NOTE: Ground preparation is optional, however we
recommend leveling area under frame of product, or
place product directly on a flat level surface before
filling with soil.
ITEM QTY.
1 4
2 2
3 2
4 4
5 2
6 6
7 4
8 1
2
Side Rail Assembly
Stand two 4" x 4" x 19" corner posts (Item 1) upright with slots facing you and
slots facing each post.
Locate a 45" x 5-1/2" side rail w/cleat (Item 2), (with cleat located at the bottom
and facing you). Install side rail w/cleat into the upper part of the slots and slide
down to the bottom of the slots.
Repeat procedure for the two remaining 4" x 4" x 19" corner posts and the 45" x
5-1/2" side rail w/cleat.
(Soil depth option: Cleats located as shown will provide a soil
depth of approximately 9". Reverse side rail w/cleat installation,
cleats located at top, if a soil depth of approximately 6" is desired).
Packaged & Inspected by:
www.gronomics.com
Parts List
PART # DESCRIPTION
1900P Corner Post, 4" x 4" x 19" w/2Dovetail Depth 12-3/4"
R4502 Side Rail w/Cleat, 45" x 5-1/2" x 1"
R4500 R4500L Side Rail, (One w/Logo), 45" x 5-1/2" x 1"
Side Rail, 14-1/2" x 5-1/2" x 7/8"
R1450
1538N
Corner Notched Bottom Board, 15-3/8" x 5-1/2" x 1"
1538 Bottom Board, 15-3/8" x 5-1/2" x 1"
Post Cap, 4-5/8"x 4-5/8"x 1 1/2"
4545
FL3652
Fabric Liner, 36" x 52"
Rustic Planter Box
Assembly Instruction
2
1
East Bethel, MN USA
(18" x 48")
3
6
4
5
Product Care and Maintenance
Western Red Cedar will turn a weathered
grey if left unfinished. Although no finish is
required for cedar when used outdoors, a
natural oil finish applied regularly will help
maintain the beauty and minimize cracking
and drying. It is recommended to use
Gronomics Garden Bed Oil (Item #
GBO-1Q), a non-toxic, food safe finish that
is very easy to apply.Apply Oil when air
and wind temperatures are between
50-90degrees. Avoid applying in
direct sunlight.
1
2
Cleat
Date:
Item #: RPB 18-48
7
8
1
Continued
763-753-7374
