Extech Instruments MultiView Series User Manual page 7

Function Range
DCA 2, 20, 200mA
(MV-130)
10A
ACA
20µA
(MV-110)
200µA
2, 20mA
200mA, 2A
10A
ACA 20, 200 mA
(MV-120)
20A
ACA 6 2, 20 200mA
(MV-130)
10A
Resistance
200Ω
(MV-110, MV-120)
2, 20, 200kΩ, 2MΩ
20MΩ
200MΩ
Resistance
200Ω
(MV-130)
2, 20, 200kΩ, 2MΩ
20MΩ
Accuracy % rdg. + digits
±(0.8% + 10 digits) 0.0001,0.001,0.01mA
±(2.0% + 10 digits) 0.001A
±(3.0% + 7 digits)
0.01µA
±(1.8% + 3 digits)
0.1µA
±(1.0% + 3 digits) 0.001, 0.01mA
±(1.8% + 3 digits) 0.1mA, 0.001A
±(3.0% + 7 digits) 0.01A
±(1.0% + 3 digits) 0.01,0.1mA
±(3.0% + 7 digits) 0.01A
±(1.0% + 10 digits) 0.0001,0.001,0.01mA
±(2.0% + 10 digits) 0.001A
±(0.8% + 3 digits)
0.1Ω
±(0.8% + 1 digits)
1, 10, 100Ω,1kΩ
±(1.0% + 2 digits)
10kΩ
± (5.0% rdg +10d) +10 dig 100kΩ
±(0.2% + 5 digits)
0.01Ω
±(0.2% + 1 digits)
0.1, 1, 10, 100Ω
±(0.5% + 5 digits)
1kΩ
Resolution Input Protection
0.2A,250V fuse
not fused
2A,250V fuse
not fused
0.2A,250V fuse
not fused
0.2A,250V fuse
not fused
250V
DC or ACrms
Comments
Frequency: 40 to 400Hz
Maximum input:
10A (MV-110, MV-130), 20A (MV-120)
Average responding
15 sec. max @ 20A
Open circuit voltage <0.7V
Ω
RH 200M range: <75%
RH other ranges: <90%
Ω
On the 200M range a 1.0MΩ offset exists.
Subtract 1.0MΩ from all readings.
