2-Wire Short-Range DSL Line Driver
CUSTOMER
SUPPORT
INFORMATION
(HDSL with V.35)
(HDSL with X.21)
Order toll-free in the U.S.: Call 877-877-BBOX (outside U.S. call 724-746-5500)
FREE technical support 24 hours a day, 7 days a week: Call 724-746-5500 or fax 724-746-0746
Mailing address: Black Box Corporation, 1000 Park Drive, Lawrence, PA 15055-1018
Web site: www.blackbox.com • E-mail: info@blackbox.com
NOVEMBER 2001
ME0006A-V35
ME0006A-X21

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ME0006A-V35 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Black Box ME0006A-V35

Summary of Contents for Black Box ME0006A-V35

  • Page 1 Order toll-free in the U.S.: Call 877-877-BBOX (outside U.S. call 724-746-5500) SUPPORT FREE technical support 24 hours a day, 7 days a week: Call 724-746-5500 or fax 724-746-0746 INFORMATION Mailing address: Black Box Corporation, 1000 Park Drive, Lawrence, PA 15055-1018 Web site: www.blackbox.com • E-mail: info@blackbox.com...
  • Page 2 FCC AND IC RFI STATEMENTS/CE NOTICE FEDERAL COMMUNICATIONS COMMISSION INDUSTRY CANADA RADIO FREQUENCY INTERFERENCE STATEMENTS This equipment generates, uses, and can radiate radio frequency energy and if not installed and used properly, that is, in strict accordance with the manufacturer’s instructions, may cause interference to radio communication.
  • Page 3 2-WIRE SHORT-RANGE DSL LINE DRIVER (HDSL WITH V.35 OR X.21) NORMAS OFICIALES MEXICANAS (NOM) ELECTRICAL SAFETY STATEMENT INSTRUCCIONES DE SEGURIDAD 1. Todas las instrucciones de seguridad y operación deberán ser leídas antes de que el aparato eléctrico sea operado. 2. Las instrucciones de seguridad y operación deberán ser guardadas para referencia futura.
  • Page 4 NOM STATEMENT 12. Precaución debe ser tomada de tal manera que la tierra fisica y la polarización del equipo no sea eliminada. 13. Los cables de la fuente de poder deben ser guiados de tal manera que no sean pisados ni pellizcados por objetos colocados sobre o contra ellos, poniendo particular atención a los contactos y receptáculos donde salen del aparato.
  • Page 5 2-WIRE SHORT-RANGE DSL LINE DRIVER (HDSL WITH V.35 OR X.21) TRADEMARKS USED IN THIS MANUAL Any trademarks mentioned in this manual are acknowledged to be the property of the trademark owners.

  • Page 6: Table Of Contents

    CONTENTS Contents Chapter Page 1. Specifications ........... . 6 2.

  • Page 7: Specifications

    2-WIRE SHORT-RANGE DSL LINE DRIVER (HDSL WITH V.35 OR X.21) 1. Specifications Clocking Modes: Internal, external, or receive recovered DTE Rate: All 64-kbps increments from 64 to 1152 kbps DTE Interface: ME0006A-V.35: DCE orientation; ME0006A-X.21: DCE or DTE DTE Connector: ME0006A-V.35: M/34 female; ME0006A-X21: DB15 female Diagnostics: V.52-compliant (511/511E) pattern generator and detector with error injection mode controlled by a front-panel switch;...

  • Page 8: Introduction

    LAN-to-LAN interconnection, and WAN access networks over 3.6 miles/5.8 km (1.054 Mbps on 24-AWG/0.5-mm wire). The HDSL Line Driver V.35 (ME0006A-V35) provides a V.35 interface on an M/34 female connector. The HDSL Line Driver X.21 (ME0006A-X21) provides an X.21 interface on a DB15 female connector. Features include loopback diagnostics, and inband SNMP/HTTP remote management capabilities through a DSL Line Driver Rack Card (ME0003C) CO and externally accessible configuration switches.

  • Page 9: Configuration

    2-WIRE SHORT-RANGE DSL LINE DRIVER (HDSL WITH V.35 OR X.21) 3. Configuration The HDSL Line Driver is equipped with two sets of eight DIP switches. This chapter describes switch locations and explains all possible configurations. Configuring the Hardware DIP Switches The 16 external switches are grouped into two eight-switch sets.
  • Page 10 CHAPTER 3: Configuration DIP-S WITCH The configuration switches on S2 allow you to specify the clocking mode and to enable/disable local and remote loop requests from the V.35 DTE. Default settings are shown in Table 3-1. Table 3-1. S2 summary. Position Function Factory Default...
  • Page 11 2-WIRE SHORT-RANGE DSL LINE DRIVER (HDSL WITH V.35 OR X.21) Switches S2-6 and S2-7: Clock Mode Use Switches S2-6 and S2-7 to configure the HDSL Line Driver for internal, external, or receive recover clock mode. Table 3-2. Clock mode. CO/CP S2-6 S2-7 Clock Mode...
  • Page 12 CHAPTER 3: Configuration DIP-S WITCH Use the eight DIP Switches in Switch S3 to enable the DTE bit rate. Table 3-4 summarizes the default positions. Detailed descriptions of each switch follow the table. Table 3-4. S3 summary. Position Function Factory Default S3-1 DTE Rate S3-2...
  • Page 13 2-WIRE SHORT-RANGE DSL LINE DRIVER (HDSL WITH V.35 OR X.21) Table 3-5 (continued). DTE bit rate. S3-1 S3-2 S3-3 S3-4 S3-5 S3-6 DTE Rate (kbps) 1024 1088 1152 NOTE The actual line rate of the Line Driver is determined by the selection of the DTE rate.
  • Page 14 CHAPTER 3: Configuration Switch S3-8: Transmit Data (TD) Sampling Point Table 3-7. Transmit data sampling point. S3-8 Setting Description Normal TD sampled on the falling edge of the HDSL Line Driver Transmit Clock (TC) Invert TD sampled on the rising edge of the HDSL Line Driver Transmit Clock...

  • Page 15: Installation

    2-WIRE SHORT-RANGE DSL LINE DRIVER (HDSL WITH V.35 OR X.21) 4. Installation Once the HDSL Line Driver is properly configured, it is ready to connect to the twisted-pair interface, to the serial port, and to the power source. This chapter tells you how to make these connections.

  • Page 16: Connecting The Hdsl Line Driver's V.35 Serial Interface

    DSL span Remote HDSL Line Driver (ME0006A-V35) Straight-through M/34 cable V.35 router (DTE) HDSL Line Driver (ME0006A-V35) (DCE) Figure 4-2. Connecting the Line Driver to a V.35 serial DTE. 4.2.2 C V.35 L DCE D ONNECTING THE RIVER TO A EVICE The Line Driver provides a V.35 (Data Circuit Terminating Equipment) interface...

  • Page 17: Connecting The Line Driver's X.21 Serial Interface

    Remote HDSL Line Driver (ME0006A-V35) Crossover M/34 cable HDSL Line Driver (ME0006A-V35) (DCE) V.35 multiplexor (DCE) Figure 4-3. Connecting the Line Driver to a V.35 serial DCE. 4.3 Connecting the Line Driver‘s X.21 Serial Interface The Line Driver supports X.21 serial port connections. This section describes how to connect the serial ports to your X.21 equipment.

  • Page 18: Opening The Case

    CHAPTER 4: Installation To modify the DCE/DTE orientation from the default position (DCE), you must open the X.21 Line Driver’s case. 4.3.2 O PENING THE To open the Line Driver’s case, insert a flat-head screwdriver into an open slot on both sides of the case, as in Figure 4-5.

  • Page 19: Connecting Power

    The Line Driver powers up as soon as it is plugged into an AC outlet; there is no power switch. WARNING There are no user-serviceable parts in the power supply. Only qualified service personnel should replace the fuse. Contact Black Box Technical Support at 724-746-5500 for details.

  • Page 20: Operation

    CHAPTER 5: Operation 5. Operation Once the Line Driver is properly configured and installed, it should operate transparently. This chapter describes power-up, reading the LED status indicators, and using the built-in loopback test modes. 5.1 Power-Up To apply power to the Line Driver, first be sure that you have read Section 4.4. The unit powers up when it is plugged into the power source.

  • Page 21: Test Modes

    2-WIRE SHORT-RANGE DSL LINE DRIVER (HDSL WITH V.35 OR X.21) • ER: blinks ON/OFF after a 511/511E test has timed out. See Section 5.3 for more information. ER flashes once to indicate that a CRC error has occurred (during normal operation) or bit errors have occurred (during 511/511E tests).

  • Page 22: Restart Procedure And Timeouts

    CHAPTER 5: Operation Framer The framer is used to determine the status of the line. In normal operation, the framer transmits and expects to receive framed packets from the far end. If the framer receives framed packets from the far end, CTS and CD will be active. If framed packets are not received, CTS and CD will be inactive.

  • Page 23: Loops And Patterns

    2-WIRE SHORT-RANGE DSL LINE DRIVER (HDSL WITH V.35 OR X.21) Table 5-1. Test mode timing. Item Elapsed Time (seconds) Startup Data Mode 511/511E Generator Enabled 60 (The generator will stop after 45 seconds.) Remote End of an RDL 511/511E Timeout 45 (The pattern generator will automatically turn off after 45 seconds.
  • Page 24 CHAPTER 5: Operation the line or at the far-end DTE interface is invalid. The remote unit will remain in the startup mode, NS LED on, CTS LED yellow, and CD LED yellow, until the local unit is taken out of the local loop mode. After the local loop is deselected, the units will both be in startup mode and the link will be established.
  • Page 25 2-WIRE SHORT-RANGE DSL LINE DRIVER (HDSL WITH V.35 OR X.21) Local Loop with 511/511E When the unit is placed into a mode 1 local loop and the 511/511E pattern generator is activated, the local pattern generator begins sending out a 511/511E pattern to the loop control block.
  • Page 26 CHAPTER 5: Operation Loop Loop Pattern Framer Framer Pattern Line Control Control Gen./Det. Gen./Det. Processor Processor Figure 5-6. Local loop mode 2 with 511/511E. Remote Digital Loop The Remote Loop uses the EOC channel (an out-of-band signaling channel) to establish the remote link. Upon the RDL switch being thrown or DTE initiation, a RDL_ON Request signal is sent to the remote unit.
  • Page 27 2-WIRE SHORT-RANGE DSL LINE DRIVER (HDSL WITH V.35 OR X.21) Remote Digital Loop with 511/511E The Remote Digital Loop with 511/511E is shown in Figure 5-8. After RDL is established, the remote unit’s restart timer is set to one minute. This has been done because when the 511/511E generator is started on the local unit, the remote framer begins seeing unframed packets.

  • Page 28: Using The V.52 (Ber) Test-Pattern Generator

    CHAPTER 5: Operation Loop Loop Line Framer Framer Pattern Pattern Control Control Gen./Det. Gen./Det. Processor Processor Figure 5-9. Data mode with 511/511E. 5.3.4 U V.52 (BER) T SING THE ATTERN ENERATOR To use the V.52 BER tests in conjunction with the remote digital loopback tests (or with local line loopback tests), follow these instructions: 1.

  • Page 29: Appendix A. V.35 Interface Pin Assignments

    2-WIRE SHORT-RANGE DSL LINE DRIVER (HDSL WITH V.35 OR X.21) Appendix A. V.35 Interface Pin Assignments Shown below are the pin assignments for the V.35 interface (M/34 female connector), DCE orientation. Pin # Signal B ....SGND (Signal Ground) C .

  • Page 30: Appendix B. X.21 Interface Pin Assignments

    APPENDIX B: X.21 Interface Pin Assignments Appendix B. X.21 Interface Pin Assignments Shown below are the pin assigments for the X.21 interface (DB15 female connector), DTE/DCE orientation. Pin # Signal 1 ....Frame Ground 2 .

  • Page 31: Appendix C. Transmission Distance Charts

    2-WIRE SHORT-RANGE DSL LINE DRIVER (HDSL WITH V.35 OR X.21) Appendix C. Transmission Distance Charts Table C-1. Transmission distance HDSL Line Driver, no crosstalk. Line Rate DTE Rates 26 AWG (0.4 mm) 24 AWG (0.5 mm) (kbps) (kbps) 64, 128 20,700 3.9 24,500 4.6 192, 256...
  • Page 32 © Copyright 2001. Black Box Corporation. All rights reserved. 1000 Park Drive • Lawrence, PA 15055-1018 • 724-746-5500 • Fax 724-746-0746...
