Xiaomi ZI5 Quick Start Manual

ZIAA/AAA Ni-MH Battery
Charger
Thank you for your choice!
Before using the device, read
the instructions carefully.
Caution
During charging, do not put anything on the device.
Do not recharge batteries, that is not designed for
this devices.
For optimum efficiency, it is recommended to use
the device with ZIAA / ZIAAA nickel rechargeable
batteries or nickel rechargeable batteries
Panasonic eneloop.
It is not recommended to take the device by wet
hands.
Do not immerse the device in water, do not let it
exposed to rain, snow, heat and avoid its use in
wet areas (eg bathroom).
After recharging, make sure you unplug the power
cord from the power supply.
If the product has been dropped or has other
damage, do not use it.
Do not disassemble or modify the device.
Do not use the device in direct sunlight.
Specifications
Model: РВ400
Input: 5.0V-1.0A
Output: 5.0V-0.5A
(АА) 1.5V-550mA х4
(ААА) 1.5V-225mA х4
Dimensions: 77х63х24.5mm
Temperature range: 0-40 С
Introduction to ZI5 Ni-MH Battery
Charger
USB port(input)
The switch for charge / discharge
Set aside Input, to charge the rechargeable
batteries
Set aside Output, to charge another device
LED indicator
Anode
АА cathode
ААА cathode
Charging
Toggle the button to Input, charge the
rechargeable nickel batteries such as
AA and AAA (any combination).
1. Make sure that you have correctly
inserted the batteries (the direction of
the positive and negative poles of the
battery relative to the device).
The image of the installation of AA batteries
The image of the installation of AAA batteries
2. Recharge the rechargeable batteries
by connecting the USB device port to the
Micro Power DC 5V.
3. Slowly flashing LED indicates normal
charging process; lLED, that constantly
lit indicates that battery charging is
complete.
