Controls and Operation
MANUAL COMPONENT ACTIVATION SCREEN (continued)
6 The Component Activation screen for the selected zone
appears. Tap the arrow to return to the Manual Component
Activation screen.
Component Activation Zone 1
Dispenser Water Baffle
Slide For More Components
COMPONENT ACTIVATION
Refrigerator Components
Dispenser
Water Enable
Baffle
Compressor
Condenser
Evaporator
Lights
7 Tap the component to activate. The component name turns
black, indicating the component is active.
8 Tap the arrow to return to the Settings screen.
MANUAL DEFROST SCREEN
1
Tap Settings .
2
Tap Service Options .
3 Tap Defrost from the Service Options screen.
4 The Manual Defrost screen appears.
Manual Defrost
Start
7041389 REVA 06/2017
Compressor Condenser
Freezer Components
Ice Maker
Water Enable
Ice Water
Defrost
Compressor
Condenser
Evaporator
Lights
5 Tap Start to begin manual defrost.
Manual Defrost
Currently Defrosting...
6 The Currently Defrosting message appears.
7 Tap the arrow to return to the Settings screen.
DISABLE COOLING ZONE SCREEN
1
Tap Settings .
2
Tap Service Options
3 Tap Zone Disable from the Service Options screen.
4 The Disable Cooling Zone screen appears with the status of
each zone.
Disable Cooling Zone
Zone 1
Enabled
5 Tap the zone to enable or disable it, then the Zone Disable
Confirmation screen appears.
6 Tap Yes to enable or disable the zone. Tap No or the arrow
to cancel.
TIP: When a zone is disabled, EE appears on the UIM.
7 Tap the arrow to return to the Settings screen.
CURRENT TEMPERATURES SCREEN
1
Tap Settings .
2
Tap Service Options
3 Tap Temps.
10
IC-24C(I)
service.subzero.com
.
Zone 2
Enabled
.
