ULTRACOM AVIUS Instructions Manual page 4

1
2
3
4
5
Isäntälaite Panta
1 VHF-antenni 1 GPS-kotelo
2 VHF-antenni
2 Vihreä/punainen
led-valo 3 Akkukotelo
3 Virtapainike 4 Virta-ikoni
4 Sininen led-valo 5 Akkukotelon kansi
5 Yhteyspainike 6 Huomiovalo
6 Akkukansi 7 Vihreä led-valo
7 Akkukannen 8 VHF-antennin tuki
sormiruuvi
8 Magneetti-ikoni
6
8
7
Mottagare
1 VHF-antenn
2 Grön/röd led
3 Strömknapp
4 Blå led
5 Anslutningsknapp
6 Batteri hölje lock
7 Batterilucka skruv
8 Magnet ikon
2
1
3 4 5
Halsband Host device
1 GPS-hölje 1 VHF-antenna
2 VHF-antenn 2 Green/red led-light
3 Batterihölje 3 Power button
4 Strömikon 4 Blue led-light
5 Batteri hölje lucka 5 Connection button
6 Varseljus 6 Battery cover
7 Grön led 7 Battery cover thumb
8 VHF-antennhållare screw
8 Magnet-icon
4
7
6
8
Collar
1 GPS-casing
2 VHF-antenna
3 Battery casing
4 Power-icon
5 Battery cap
6 Warning strobe
7 Green led-light
8 VHF-antenna holder
