2.6.5 Sidelight Alarm (SA)

2.7

ALARM TESTING

2.7.1
2.7.2
2.7.3
2.7.4
M.E-2009.E-1DB2
3/25/07 – rev. 5/28/09
E-1DB2 CONTROLLER
Connect the customer's alarm common to plug J3, terminal #2. Connect the
customer's alarm wire to plug J3, terminal #1, for normally open (or) terminal
#3, for normally closed monitoring.
To test alarms, follow these procedures using an "ohm" meter between
alarm common and alarm points.

White Strobe Failure (SF)

White strobe failure testing can be performed in the daymode operation.
Check for status of strobe beacon. Turn "on" switch S1 on PCB #1, and
status will change after a nine (9) second delay. After test, turn switch "S1"
to the normal operating position (down position).

Red Strobe Failure (RF)

Red strobe failure testing can be performed in the nightmode operation.
Check for status of strobe beacon. Turn "off" switch SW2 on controller panel
and status will change after a ten (10) second delay. This testing will cause
the unit to go into the back-up white strobe operation. To clear this situation,
turn "on" switch SW2, and reset the breaker.

Power Failure (PF)

While the controller is in normal operation, shut off power to the controller at
the breaker panel. Alarm should be prompt. Reset the breaker to resume
normal operation.

Photocell (PC)

Controller should be in the daymode of operation when performing this test.
Check status of operation. Turn "on" switch SW1, (or) cover the photocell
and operation status should change state. After test, turn switch SW1 to the
normal operating position.
