Fig.5 and Fig. 6: 6V/ 12V
LCD charging block diagram
Precau ons and Opera ng Instruc ons
1) Precau ons:
a. The supply voltage of the product is 220~240VAC; please make sure that the mains voltage meets the
specifica ons of the product before using;
b. The charger is suitable for 6V/12V regular and Gel ba eries with 5Ah ~ 120Ah capacity;
c. Clamp the ba ery anode with the red clip of the output line, and clamp the cathode with the black clip; it will
report error if the polarity is reverse;
d. The working environment of the product is 0°C~40°C; do not use beyond this range of temperature;
e. Before charging the ba ery, in order to prevent the equipment connected to the ba ery from damage or
unnecessary influence, disconnect the ba ery and the equipment before charging the ba ery;
2) Opera ng instruc ons:
A. Connec on and reverse polarity: select the ba ery to be charged, confirm the input voltage and then insert the
power plug, enter into the ini aliza on interface as follows Fig. 7; clamp the red clip of the output side to the anode
of the ba ery, and clamp the black clip to the cathode; if the polarity is reverse, the red (Fault) LED flashes at 1Hz,
and LCD displays as shown in Fig. 8
Fig. 7 Fig. 8
