2.
Appearance and LCD Diagram
1) Product structure
H: LCD
F : DEL power (green)
2) Schéma LCD
a: reverse polarity icon
b: wrong battery icon
c: 12V battery icon
d: 6V battery icon
e: analog battery icon
Fig. 1 LCD diagramm
A : Power input 220vlt
G: Fault DEL (red)
C : Bottom shell
Fig. 1 Structure Diagram
Fig. 2 LCD Diagram
E : Mode button
f: slow mode icon
g: fast mode icon
h: LowTemp mode icon
i: Digit/character icon
3
D: Top Shell
B : Output :
red: Positive
Black : Négative
ENG
