TM00358 Rev. A

4.3 TURRET AIRCRAFT INSTALLATION

Installation of the turret into an aircraft requires three separate steps:
• Step 1 – Inspection for corrosion
• Step 2 – Surface sealant application
• Step 3 – Installation and mechanical fasteners
Table 4-2 Turret Installation — Parts
Description
Turret
Turret shipping case
1/4"-28 x ( ~" ) Cap screw,
socket headed
Table 4-3 Turret Installation — Consumables
Description
Joint compound, non-
chromate corrosion inhibitive
New, lint-free cloths that
conform to AMS 3819
Isopropyl Alcohol
L-3 WESCAM
All Rights Reserved
Part Number
42390
41179
–
Part Number
CA 1000 PRC-DeSoto International
–
–
Chapter 4 - Turret Aircraft Installation
Quantity
1
1
8 • Installation screws are
Customer Furnished
Equipment that must
conform to NAS 1351-4
• Screw length is installation
specific.
• Make sure screw length
extends 1 cm (3/8") below
the mating surface.
• Torque screws to
100
(11 Nm
Manufacturer
• Consult manufacturer's
Technical Data Sheet for
use instructions and
MSDS for material
handling safety.
Numerous • Consult a CA 1000
technical data sheet for
surface preparation
guidance.
• Use one cloth to clean and
another cloth to wipe.
– • Remove dirt, grease, and
lubricants prior to
compound application.
Notes
±
10 in-lbs
±
1.1 Nm)
Notes
October 2007
75
