Chapter 2 - Profiles Menu

2.14 PROFILES MENU

The Profiles Menu provides operators with the ability to save and retrieve specific configuration profiles, or they can
restore the factory defaults. From various other menu options, operators can configure the entire system and tailor
the settings to their preference or tailor options for different mission types. Operators can save these settings, as a
profile, that can be later to recalled and loaded to reconfigure the system. The CURRENT PROFILE field displays
the profile that is currently selected.
Save a Modified Profile
1. Using the ZOOM switch, move the cursor down to the CURRENT PROFILE and use the SENS switch to
select the modified profile name.
Note: Make sure you have selected the correct CURRENT PROFILE before saving. All previous settings for the
selected CURRENT PROFILE will be replaced by the new settings.
2. With the profile selected, move the cursor down to SAVE at the bottom of the screen and press the MENU
button. This action will save the current system settings and a screen prompt will appear asking you to
confirm the save.
3. Move the cursor to CONFIRM and press the MENU button.
Load a Profile
1. If the System Status main menu is not displayed, press the MENU button.
2. Using the ZOOM switch, move the cursor to the PROFILES option.
3. Press the MENU button.
4. Move the cursor to the CURRENT PROFILE and use the SENS switch to select the desired profile.
5. With the desired profile selected, move the cursor down to LOAD at the bottom of the screen.
6. Press the MENU button.
October 2007
48
LEVEL 2 - PROFILES
NAME
USER DEFAULT
CURRENT PROFILE
USER DEFAULT
FACTORY DFLT SAVE

Figure 2-31 Level 2 Profiles Menu

LOAD DONE
