L3 Communications MX-15i Operation & Maintenance Manual page 61

TM00358 Rev. A
Table 2-13 Status Information and Controls in the Level 2 Mission Menu
Field
TERRAIN ALTITUDE
SET TIME
FACTORY DFLT
DONE
L-3 WESCAM
All Rights Reserved
Values
-457 to 15 240m Action is linked to the Terrain Altitude Source setting:
(1500 to 50 000 ft) • When referencing external navigational equipment, this field dynamically
displays the updated values of the terrain altitude.
• When manual, the operator can enter a static value.
ACTION FIELDS
– Saves the configured time settings.
– Resets all user configured options to factory default settings.
– Exits menu.
Chapter 2 - Mission Menu
Description
October 2007
45
