2.7 IR MENU

The IR menu (infrared) provides status information and controls for the IR sensor. Operators can use this menu to
calibrate the IR camera's focal plane array (similar function to film or digital CCD) by selecting one of 2 options:
• 1-Point – A scene based thermal profile
• 2-Point – Both a scene based and a built-in infrared source thermal profiles
Operators can also access a Level 3 Miscellaneous sub menu for additional diagnostic information in the form of
sensor component temperatures.
LEVEL 2 - IR
MODE
ALARMS
FOV
FOCAL LENGTH
FOCUS
SENSITIVITY
LEVEL
TEMP STATUS
POLARITY
TEMPORAL PROC
SPATIAL PROC
EZOOM
CALIBRATION
SCENE SETUP
CALIBRATE

Table 2-8 Status Information and Controls in the Level 2 IR Menu

Field
TEMPORAL PROC LOW, MEDIUM,
HIGH, OFF
SPATIAL PROC ON, OFF
EZOOM 1x, 2x and 4x
CALIBRATION 1 POINT
2 POINT
L-3 WESCAM
All Rights Reserved
OPERATIONAL
OK
26.67 deg
27 mm
133
AUTO
AUTO
OK
WHITE HOT
LOW
ON
1X
1 POINT
DEFAULT
MISC ALARMS BIT DONE
Figure 2-24 IR Menu
Values
VALUE FIELDS
Enables or disables temporal processing which can be used to remove pixel
flicker or variations from the image.
Enables or disables spatial processing which can be used to improve image
sharpness and improve edge detection.
Sets the degree of electronic zoom:
• At 1x zoom, the video's field of view = the optical field of view.
• At 2x zoom, the video's field of view = ½ of optical field of view.
• At 4x zoom, the video's field of view = ¼ of optical field of view.
Note: The 4x option is only available on some IR sensors and not available on
the VNFOV.
Selects a 1-Point calibration option to remove of common video artifacts and
reset dynamic range of the thermal image. This is the quickest calibration and
most recommended option for operator use.
Selects a 2-Point calibration option to remove bright video artifacts, recalculates
pixel uniformity measures and resets dynamic range of thermal image. This is
the longest calibration and not recommended for operator use. Use only when a
1-Point calibration does not yield satisfactory results.
LEVEL 2 - IR
LEVEL 3 - MISCELLANEOUS
TEMPERATURES
AMBIENT 1
AMBIENT 2
PROCESSOR
LENS
EXPANDER
COMPRESSOR
WAE
−
Levels 2 and 3
Description
Chapter 2 - IR Menu
22.4 deg C
21.7 deg C
37.8 deg C
24.4 deg C
34.4 deg C
28.3 deg C
30.0 deg C
DONE
