2.6 EOW MENU

The EOW menu (electro-optic wide) provides status information and controls for the EOW imaging sensor.
Operators can also access a Level 3 Miscellaneous sub menu for additional diagnostic data in the form of sensor
component temperatures.
LEVEL 2 - EOW
MODE
ALARMS
FOV
FOCAL LENGTH
FOCUS
SENSITIVITY
TEMP STATUS
FILTER

Table 2-7 Status Information and Controls in the Level 2 EOW Menu

Field
MISC
ALARMS
BIT
DONE
FOV Optical: 47.18°-2.0°,
Digital: 2.0°-0.67°
FOCAL Optical: 2.4-60 mm,
LENGTH Digital: 60-180 mm
FOCUS 1 m to Infinity
SENSITIVITY AUTO
MAN
L-3 WESCAM
All Rights Reserved
OPERATIONAL
OK
13.16 deg
28 mm
42
AUTO
OK
COL
MISC ALARMS BIT DONE
Figure 2-23 EOW
Values
ACTION FIELDS
– Displays Miscellaneous menu.
– Displays Alarms page with BIT test results for the EOW sensor.
– Initiates an EOW BIT.
– Exits menu.
STATUS INDICATORS
Current horizontal FOV in degrees.
Current focal length in millimeters.
Focus position expressed as an estimated distance to the object that sensor is
focused upon. Units are in meters.
Note: Do not use number for reporting target distance, this is a very crude
distance estimation.
System has been enabled for automatic control of image brightness.
Current value for manual sensitivity. Operators can increment the sensitivity to
control image brightness from the Hand Controller.
LEVEL 2 - EOW
LEVEL 3 - MISCELLANEOUS
TEMPERATURES
AMBIENT 1
AMBIENT 2
PROCESSOR
LENS
CAMERA
−
Levels 2 and 3
Description
Chapter 2 - EOW Menu
22.4 deg C
21.8 deg C
38.3 deg C
22.7 deg C
35.5 deg C
DONE
