TM00358 Rev. A
Table 2-4 Fields in the Level 1 System Status (Main) Menu (Continued)
Field
ALARMS
SYSTEM BIT
DONE

Table 2-5 Status Indications in the System Status Main Menu

Status State
OK, STARTUP
MINOR,
MAJOR
– N/A
OK OPERATIONAL
OK STOWED
MINOR OPERATIONAL
MAJOR OPERATIONAL
MAJOR FAILED
L-3 WESCAM
All Rights Reserved
Displays the Alarms page with BIT test results for the entire system.
Initiates a full sequence of BITs for all system components – the same sequence executed on
power up. This BIT can be used to reset the system instead of cycling power to the turret.
Exits menu.
Description
Component Initializing:
• Some components are warmed or cooled
before they can be operated.
Communication failure with component.
Component is in a fully functioning state.
Turret is operational but in the Stow position
Component BIT test failed but still functional:
• Component capabilities are out of tolerance,
e.g. focus position exceeded tolerance set
point.
Component BIT test failed but still functional:
• The system has forced a partial shutdown of
capability. For example, the EOW mechanism
caused Iris function to shutdown, but zoom and
focus capability remain.
Component BIT failed and is shutdown.
• The system has forced a shutdown of a
capability. For example, the internal gimbal
temperature is too hot so the EON is shutdown.
Chapter 2 - System Status Menu
Description
Recommended Action
None.
Review the Alarms page.
None.
Steer turret to Forward or manual
position to establish video.
Review BIT from the Alarms page.
Review BIT from the Alarms page.
Review BIT from the Alarms page.
October 2007
31
