Executing an Action Field
1. If the System Status main menu is not displayed, press the MENU button on the Hand Controller.
2. Click the ZOOM switch up or down to select an
3. Press the MENU button to execute that field's action.
Changing the Value for a Value Field
1. If the System Status main menu is not displayed, press the MENU button on the Hand Controller.
2. Click the ZOOM switch up or down to select a desired menu option.
3. Press the MENU button to display the sub menu option.
4. Click the ZOOM switch up or down to select a desired menu option.
5. Click the SENS switch to change the option's value. Clicking up on the toggle switch will increase the value,
while clicking down will decrease the value.
L-3 WESCAM
All Rights Reserved
Action Field option.
