TM00358 Rev. A
Target Coordinates. Reports the target's geographic location data (lat/long). The target coordinates are system
calculated using the aircraft's position and turret's orientation to determine location. Display units can be configured
by the operator. The location data and the accuracy of that measurement is determined by the current
measurement mode.
• In LOS mode – target coordinates are updated every 1 to 3 seconds – depending upon the target's
calculated slant range. LOS is the default measurement state.
• INS Alignment mode – Reports the current state of INS alignment checks. No target coordinates will be
reported. When aligned, the default LOS measurement state is initiated.
TGT
INS STATE
HEADING
INS Mode

Figure 2-13 Measurement Modes and Changes to Target Coordinate Data

2.2.4

North Indicator

The North Indicator arrow is located in the top-left side of the display, and the arrow's point indicates the direction of
True North. Operators would use the arrow as a universal point-of-reference for describing ground movements
relative to an earth orientation rather than the aircraft's position. The arrow provides a witness marker on the video
so that the line-of-sight, of the captured video, can be later related to a cartographic map's orientation where the
page layout of north is always up. Display of this overlay element can be disabled.
L-3 WESCAM
All Rights Reserved
a
Terrain
LOS Mode

Figure 2-12 Slant Range Measurement Modes

OFF NONE
TGT LOS
27:46:05N
82:57:22W
LOS Mode
22NV2006 MAN
09:45:12
UTC+0.0
N

Figure 2-14 North Arrow Graphic

c
b
90
Sea Level
22NV2006 MAN TEM
09:45:12 SPA
UTC+0.0
N
01
00
-01
34 35 00 01 02
ACFT
27:46:12N 352°
82:57:16W 11050FT 679FT
22NV2006 MAN TEM 90 COL AUTO 2000
EOW
09:45:12 SPA 2X DFLT 50 2%
UTC+0.0
N
N
01
00
-01
34 35 00 01 02
ACFT TGT LOS
27:46:12N 352° 27:46:05N
153°
82:57:16W 11050FT 679FT 82:57:22W
35.3NM
Chapter 2 - Video Status Overlays
90 COL AUTO 2000
EOW
2X DFLT 50 2%
TGT LOS
27:46:05N
153°
82:57:22W
35.3NM
October 2007
