Chapter 2 - Video Status Overlays
2.2.2

Messaging Graphics

Messaging graphics provide status information about the system and its current operational condition. There are
two types of messages that can be displayed in an overlay.
• Pop-up alerts
• Sensor states
POP-UP ALERTS
SENSOR STATES
34 35 00 01 02
°
352
11050FT
Pop-up Alerts. Displayed on all video displays and messages will remain until they are cleared by pressing the
MENU button. Messages will be displayed when:
• a system BIT detects a failure
• an external system forwards a message for display
Once cleared from the video display, BIT alerts can be later retrieved from a user menu Alarms page – where
messages are retained until the system component's function is restored.
October 2007
20
Max FOV
Min FOV
Current FOV

Figure 2-7 Relative Zoom Status Bar

TEM EOW 90 COL
SPA 2X DFLT
°
153
679FT
35.3NM
Figure 2-8 Pop-Up Alerts & Status Messages
Wide FOV Narrow FOV
22NV2006 MAN TEM
EOW
09:45:12 SPA
UTC+0.0
N
01
00
-01
34 35 00 01 02
ACFT
27:46:12N 352°
82:57:16W 11050FT 679FT
TM00358 Rev. A
90 COL AUTO 2000
2X DFLT 50 2%
TGT LOS
153° 27:46:05N
35.3NM 82:57:22W
