Chapter 2 - Hand Controller Controls
2.1.2 Hand Controller – Secondary Button Controls
3
2
1
14
13
12

Table 2-2 Hand Controller Secondary Button Control Functions

Item Control
(1) MENU button
(2) *LASER button
(3) *GEO FOCUS
button
* Optional functions. These controls will have no effect if the hardware or software features have not been integrated as part
of the turret system.
October 2007
14
4
GEO
MENU LASER MAP
FOCUS
CNTRL
LRF TX
AUTH
11

Figure 2-3 Hand Controller Top Buttons

Menu:
• Press once to display the user menus.
MENU
• When in a user menu, press once to select a menu option.
• Press and hold for 2 seconds to exit from all user menus.
Sensor:
• For the Video-In-Control, press to clear displayed Pop-up alerts.
• Press and hold for 2 seconds to fire the Laser Illuminator.
LASER
Note: Laser will only fire when all arming conditions are met.
• Press to enable or disable sensor Geo Focus.
GEO
• Push and hold for 2 seconds to enable Geo Focus Trim mode. Use the
FOCUS
focus wheel to adjust the sensor's focus.
• When in Trim mode, press once to return to Geo Focus with trim settings
applied.
Note: In Geo-focus mode, all sensors are auto-focused to a distance set by
the range-to-target value.
Note: In Trim mode, the focus wheel sets a trim offset that compensates for
errors in calculated or measured target distances.
IR
2X STOW
GATE
IR
POL SCENE
CAL
Description
TM00358 Rev. A
5
6
7
8
9
10
