EOW BIT Codes 5.x

Table 5-4 Failure Descriptions for 5.x BIT Codes

BIT
Message
#
5.1 Thermal Shutdown
5.2 Focus Position Error
5.3 Focus Failure
5.4 Zoom Position Error
5.5 Zoom Failure
5.6 Iris Position Error
5.7 Iris Failure
5.8 Extender Position
Error
L-3 WESCAM
All Rights Reserved
Category Failure Description
MAJOR Camera/lens temperature is outside
the operating limits. (Too hot or too
cold.)
MINOR Focus elements failed to reach a
specific position in a specific time.
MAJOR Focus servo loop of EOW sensor
not responding properly.
No focus control available for EOW
sensor.
MINOR Zoom elements failed to reach a
specific position in a specific time.
MAJOR Zoom servo loop of EOW sensor
not responding properly.
No zoom control available for EOW
sensor. Focal length will be
approximately its value at time of
failure.
MINOR Iris elements failed to reach a
specific position in a specific time.
MAJOR Iris servo loop of EOW sensor not
responding properly.
Sensitivity control will not work
properly under certain lighting
conditions. For example, if Iris is
stuck open, video will be overloaded
in full sunlight conditions.
MINOR Extender elements failed to reach a
specific position in a specific time.
Chapter 5 - BIT Error Codes
Recommended Action
If cold, wait for built in heaters to
warm up the lens. If hot, the internal
temperature is too hot. If loss of
EOW camera impacts mission, turn
off system and allow to cool. If
problem persists, contact L-3
Wescam.
Verify that EOW sensor focus can
still be adjusted. If focus control loss
impacts mission, replace turret.
Execute a BIT from the Level 2 EOW
Menu. If failure persists, replace
turret.
Verify that EOW sensor focal length
can still be adjusted. If zoom control
loss impacts mission, replace turret.
Execute a BIT from the Level 2 EOW
Menu. If failure persists, replace
turret.
Verify whether EOW, when
configured in auto mode, can still
adjust to changing scene intensity
levels. If capability loss impacts
mission replace turret.
Execute a BIT from the Level 2 EOW
Menu. If failure persists, replace
turret.
Warning only. No action. Contact L-3
Wescam.
