Hanskamp MultiDos 035-000-000 Series Installation And Operating Instructions Manual

Liquid dosing system
Hide thumbs Also See for MultiDos 035-000-000 Series:

Advertisement

Quick Links

Download this manual
MultiDos 035-000-000
036-000-000
Vloeistof Doseersysteem
Liquid Dosing system
Flüsigkeit Dosiersystem
Liquide Systeme de dosage
EN
Installation and operating instructions
Item number: 010-100-000
Date: Nov 2017
Doetinchem,
Version 1.8 - Translation of original instructions for use
The Netherlands
According to Annex 1 chapter 1.7.4 Machine guideline 2006/42/EG
www.hanskamp.nl/en

Advertisement

loading
Need help?

Need help?

Do you have a question about the MultiDos 035-000-000 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Hanskamp MultiDos 035-000-000 Series

Summary of Contents for Hanskamp MultiDos 035-000-000 Series

  • Page 1 Liquid Dosing system Flüsigkeit Dosiersystem Liquide Systeme de dosage Installation and operating instructions Item number: 010-100-000 Date: Nov 2017 Doetinchem, Version 1.8 - Translation of original instructions for use The Netherlands According to Annex 1 chapter 1.7.4 Machine guideline 2006/42/EG www.hanskamp.nl/en...

  • Page 2: Manual Contents

    All information in this manual has been compiled with care. Hanskamp shall not be lia- ble for errors or faults in this manual. The recommendations are meant to serve as guidelines.
  • Page 3 Dosing system – Dosiersystem – Systeme de dosage - Doseersysteem Introduction MultiDos by Hanskamp, a proven, sustainable technique enabling you to very easily dose the right quantity of liquids per day and per cow. Smart, fast and affordable. MultiDos doses liquid propylene glycol like gravy on top of the feed chunks.
  • Page 4 • Only use approved spare parts, and make sure they are only installed by authorized technicians. 4 - 30 Hanskamp AgroTech B.V. (the Netherlands) www.hanskamp.nl/en...
  • Page 5 Before the electrical supply is attached to the MultiDos, make sure all parts are tight and that all the parts are in good condition. • Contact your nearest milking equipment dealer if you have any questions. 5 - 30 Hanskamp AgroTech B.V. (the Netherlands) www.hanskamp.nl/en...
  • Page 6 General safety messages appear in this safety messages section. Specific safety messages are in applicable parts of this manual when potential hazards may occur if the instructions or procedures are not followed. 6 - 30 Hanskamp AgroTech B.V. (the Netherlands) www.hanskamp.nl/en...

  • Page 7: Installation Instruction

    Keto-protect which are based on water or oil. The MultiDos is not suitable for fluids with a high viscosity. The MultiDos can also as the PipeFeeder and other Hanskamp dosators be linked to any general feed system. This instruction will help you to install the MultiDos-system (figure 1.).
  • Page 8 Attention! Make sure that the PVC hose keeps its shape during the mounting of it. Don’t pull the tie-wraps too hard, this can pinch the hose. For nozzle assembly see page 22. 8 - 30 Hanskamp AgroTech B.V. (the Netherlands) www.hanskamp.nl/en...
  • Page 9 15. Install the pump with the corresponding screws (art.nr. 003-510-000) evenly by hand. Take care! HanskampQualityTube is not suitable for acids. A hose set suitable for acids is available from Hanskamp. 9 - 30 Hanskamp AgroTech B.V. (the Netherlands) www.hanskamp.nl/en...
  • Page 10 Attention! Cut the hose off straight. When the hose is cut crooked, may im- pair the operation. 17. Turn the rotor of the pump loose by hand (counter-clockwise), and remove it (fig.12) Attention! By loosening of the rotor by hand, minor injuries can occur. 10 - 30 Hanskamp AgroTech B.V. (the Netherlands) www.hanskamp.nl/en...
  • Page 11 With the last turn press the HanskampQualityTube into the recess of the pump housing. The hose is now wedged in-between the rollers and the pump housing. Tighten the rotor by hand on the motor shaft (fig. 19 and 20). 11 - 30 Hanskamp AgroTech B.V. (the Netherlands) www.hanskamp.nl/en...
  • Page 12 Check periodical the quantity and cali- brate if necessary. When the HanskampQualityTube is worn by intensive use (leaking), replace it according described steps. A repair kit is available by Hanskamp. Also check the rollers and bearings for wear. Also these parts are available as a repair kit by Hanskamp.
  • Page 13 27. Then secure the mounting material.( Mounting mate- rial is not included). Distance between the tube and the plate: ± 8mm 13 - 30 Hanskamp AgroTech B.V. (the Netherlands) www.hanskamp.nl/en...
  • Page 14 Attention! By loosening of the rotor by hand, minor injuries can oc- cur. Attention! Hanskamp only guarantees a correct operation when the suction hose is 2 meters or shorter. Use the 5 meter hose as a delivery hose. Attention! HanskampQualityTube is not suitable for acids. A suitable hose kit for acids can be ordered from Hanskamp upon request.
  • Page 15 (diag. 35) Take care! Always cut the hose square. If the hose is cut obliquely this can adversely affect the operation. Motorcable to the control unit Suction hose delivery- hose 15 - 30 Hanskamp AgroTech B.V. (the Netherlands) www.hanskamp.nl/en...
  • Page 16 A repair kit is available by Hanskamp. Also check the rollers and bearings for wear. Also these parts are available as a repair kit by Hanskamp. We recommend to disconnect the rotor when the system is temporarily decommis- sioned.
  • Page 17 In ALPRO Menu 2:1 or Menu 2:6 In FP204 Menu 2 (F9) General 0,05kg = ± 50ml liquid additive. Calibrition See ‘DeLaval ALPRO/feeding system book’ or ‘DeLaval ALRPO/program description in- struction book.’ 17 - 30 Hanskamp AgroTech B.V. (the Netherlands) www.hanskamp.nl/en...
  • Page 18 Configuration for propylene glycol is similar to configuring for concentrates. If the cali- bration has been multiplied by factor 10, the configuration should also be multiplied by factor 10. Example: Feedstuff 3 is configured by 1kg to equal 100ml 18 - 30 Hanskamp AgroTech B.V. (the Netherlands) www.hanskamp.nl/en...
  • Page 19 No part of this publication may be reproduced or made public without prior permission in writing from Hanskamp AgroTech BV. Although this publication was put together with the utmost care, Hanskamp AgroTech is not liable for any damage that might arise due to errors or gaps in this publication.
  • Page 20 Leaking feed-through coupling Hose too loose on the cou- Mount a hose clamp (art. no 001-153-000) on pling the coupling/hose 20 - 30 Hanskamp AgroTech B.V. (the Netherlands) www.hanskamp.nl/en...
  • Page 21 The Netherlands, Doetinchem 30-09-2015 H.J. Hanskamp 21 - 30 Hanskamp AgroTech B.V. (the Netherlands) www.hanskamp.nl/en...
  • Page 22 003-518-000: Dill holes to mount the hose and nozzle, insert the hose trough the center hole and mount the nozzle to the hose. Then mount the nozzle and tighten the bolts. Attention! Always mount the nozzle vertically. 003-518-000 Nozzle cover 22 - 30 Hanskamp AgroTech B.V. (the Netherlands) www.hanskamp.nl/en...
  • Page 23 Art. Nr.: 035-321-000 = • A MultiDos system suitable for DC control (portion dosage); • Consists of 2 pumps; • Built in the container (34 ltr) with blue cover; Cover Torque Remove 23 - 30 Hanskamp AgroTech B.V. (the Netherlands) www.hanskamp.nl/en...
  • Page 24 MultiDos Dosing system – Dosiersystem – Systeme de dosage - Doseersysteem Annex 3 Exploded view wall mount Wall mount Torque = 8Nm Remove! 24 - 30 Hanskamp AgroTech B.V. (the Netherlands) www.hanskamp.nl/en...
  • Page 25 MultiDos Dosing system – Dosiersystem – Systeme de dosage - Doseersysteem Bijlage 4 Exploded view container with 2 pumps & pump MultiDos Cover Torque remove 003-525-000 25 - 30 Hanskamp AgroTech B.V. (the Netherlands) www.hanskamp.nl/en...
  • Page 26 Dosing system – Dosiersystem – Systeme de dosage - Doseersysteem Bijlage 5 exploded view Rotor 003-524-000 only in combination with HanskampQualityTube 003-512-000 of 003-512-002 003-524-001 only in combination with HanskampQualityTube 003-512-005 (black rollers) 26 - 30 Hanskamp AgroTech B.V. (the Netherlands) www.hanskamp.nl/en...
  • Page 27 Temperature of fluid being transported as well as temperature of the operating environment Frictional drag due to improper maintenance or wearing of rollers and guides Twisting, kinking, or excess lengths of the HanskampQualityTube installed in the MultiDos. Wall thickness and thickness variation 27 - 30 Hanskamp AgroTech B.V. (the Netherlands) www.hanskamp.nl/en...
  • Page 28 Carefully set up and monitor each of the foregoing variables during use sof the HanskampQualityTube in the MultiDos. Read and heed the instructions of Hanskamp (manufacturer) or (milking machine) dealer of the apparatus, the MultiDos, regarding HanskampQualityTube installa- tion, pump rollers, guide rollers and supply channel maintenance and calibration.
  • Page 29 036-*4*-00* 011-095-000 RIM motor 28RPM 24VAC with feed- back 036-*4*-00* 001-652-000 Intelligent motor 28RPM 036-*7*-00* 011-125-000 RIM motor 28RPM 24VAC/DC pulse controlled, with feedback 036-*8*-00* 001-001-000 Silver motor 40RPM 24V DC 29 - 30 Hanskamp AgroTech B.V. (the Netherlands) www.hanskamp.nl/en...
  • Page 30 Dosing system – Dosiersystem – Systeme de dosage - Doseersysteem Hanskamp AgroTech B.V. Broekstraat 17 7009 ZB Doetinchem The Netherlands Tel: +31 (0)314 - 393 797 Fax: +31 (0)314 - 393 826 www.hanskamp.nl 30 - 30 Hanskamp AgroTech B.V. (the Netherlands) www.hanskamp.nl/en...
