INSTRUCTIONS-PARTS LIST
This manual contains important
warnings and information.
READ AND KEEP FOR REFERENCE.
INSTRUCTIONS
Wall Mount
30:1 RATIO PRESIDENT
HYDRA-SPRAY PUMP
3000 psi (210 bar) Maximum Working Pressure
100 psi (7 bar) Maximum Input Air Pressure
Model 222-268, Series A
For cold spray systems
Includes pump and wall bracket
Model 221-123
For heated spray systems
Includes pump 222-268, Viscon Heater*,
heater mounting kit 222-269, and circulating kit 222-270
*
Specify desired voltage of heater
(see page 18 for available models).

TABLE OF CONTENTS

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
GRACO INC. P.O. BOX 1441 MINNEAPOLIS, MN 55440-1441
. . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . .
COPYRIGHT 1988, GRACO INC.
2
5
13
14
18
19
19
20
20
307-930
Rev. E
Supersedes Rev. D
Model 222-268 Shown
05409

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PRESIDENT HYDRA-SPRAY A Series and is the answer not in the manual?

Questions and answers

Related Manuals for Graco PRESIDENT HYDRA-SPRAY A Series

Summary of Contents for Graco PRESIDENT HYDRA-SPRAY A Series

  • Page 1: Table Of Contents

    ........Graco Toll-Free Phone Numbers ... . . 05409 Model 222-268 Shown GRACO INC. P.O. BOX 1441 MINNEAPOLIS, MN 55440–1441 COPYRIGHT 1988, GRACO INC.

  • Page 2: Warnings

    This equipment is for professional use only. Read all instruction manuals, tags, and labels before operating the equipment. Use the equipment only for its intended purpose. If you are not sure, call Graco Technical Assis- tance at 1–800–543–0339. Do not alter or modify this equipment.
  • Page 3 WARNING WARNING INJECTION HAZARD Spray from the gun, leaks or ruptured components can inject fluid into your body and cause ex- tremely serious injury, including the need for amputation. Fluid splashed in the eyes or on the skin can also cause serious injury. Fluid injected into the skin might look like just a cut, but it is a serious injury.
  • Page 4 WARNING WARNING FIRE AND EXPLOSION HAZARD Improper grounding, poor ventilation, open flames or sparks can cause a hazardous condition and result in a fire or explosion and serious injury. Ground the equipment and the object being sprayed. Refer to Grounding on page 5. If there is any static sparking or you feel an electric shock while using this equipment, stop spraying immediately.

  • Page 5: Installation

    Installation Grounding WARNING To reduce the risk of static sparking, ground the pump INJECTION HAZARD and all other spray equipment used or located in the The system pressure must be manually spray area. Check your local electrical code for de- relieved to prevent the system from tailed grounding instructions for your area and type of starting or spraying accidentally.
  • Page 6 Install a second bleed valve (F) in the main air line, to iso- drawings and lists on pages 14-17. late the accessories for servicing. Accessories mentioned are available from your Graco distributor (see page 18). If you supply your own acces- WARNING sories, be sure they are adequately sized to meet your system’s requirements.
  • Page 7 HOSE AND GUN CONNECTIONS (supplied with the bracket) from below the wall bracket. Connect one end of the fluid hose (D) to the filter outlet nipple (11) and the other to the fluid inlet of the gun (E). Do 3. Apply pipe sealant (3) to one end of the 1/2 npt nipple not install the spray tip in the gun yet.
  • Page 8 INSTALLING A HEATED SYSTEM Installing Heater Mounting Kit 222-269 Use the following procedures to install Model 221-123 WARNING Heated System, or to convert an existing Model 222-268 to a heated system. The V iscon Heater is available in three voltages (see page 18). Specify which voltage you Before installing the heater, heater mounting kit and circulating kit, follow the Pressure Relief Procedure desire.
  • Page 9 Installing Circulating Kit 222-270 4. Place a lockwasher (35 ) and washer (36 ) on the mounting stud, and insert the stud through the WARNING mounting hole in the right side of the pump wall bracket (7). Secure the regulator with a lockwasher (35 ) and nut (37 ) on the inside of the pump wall Before installing the heater, heater mounting kit and bracket.
  • Page 10 PART OF HEATER (39) SPECIFY DESIRED HEATER VOLTAGE BODY MUST POINT DOWN 05412 Fig. 3...
  • Page 11 CONVERTING TO A TWO-GUN SYSTEM Model 221-123 (Refer to Fig 4 and the Parts Drawing on page 16) To convert your sprayer to a two-gun system, refer to the following applicable paragraph for your model. Order the WARNING parts listed, and perform the assembly procedure. Before performing this procedure, follow the Pres- Model 222-268 (Refer to Fig 4 and the Parts Drawing sure Relief Procedure on page 5;...
  • Page 12 DETAIL A: HOSE CONNECTIONS AT DETAIL B: ASSEMBLY OF HOSE AND GUN (MODEL 222-268) FLUID FILTER (MODEL 222-268) FIRST SECOND GUN) GUN) 05415 05413 DETAIL D: CONNECTIONS AT BACK PRESSURE REGULATOR DETAIL C: HOSE CONNECTIONS AT (MODEL 221-123) FLUID FILTER (MODEL 221-123) (TO FIRST SECOND GUN)

  • Page 13: Operation/Maintenance

    WARNING Keep the wet-cup filled with Graco Throat Seal Liquid (TSL) to help prolong the packing life. Check the tight- ness of the packing nut weekly. The packing nut should For your safety, before operating the equipment be be tight enough to prevent leakage –...

  • Page 14: Parts Drawings And Lists

    Parts Drawing Model 222-268, Series A Includes items 1-21 PART OF ITEM 7 05418...
  • Page 15 Parts List Model 222-268, Series A Includes items 1-21 NO. PART NO. DESCRIPTION NO. PART NO. DESCRIPTION 223-586 30:1 PRESIDENT PUMP 101-180 GAUGE, pressure, air; See 306-981 for parts 0-200 psi (0-14 bar) 166-392 GASKET 187-357 ELBOW, street, 90 ; 110-110 SEALANT, pipe, sst;...
  • Page 16 Parts Drawing Model 221-123 Includes items 1-40 PART OF SPECIFY DESIRED HEATER (39) HEATER VOLTAGE ARROW BODY MUST POINT DOWN 05412...
  • Page 17 Parts List Model 221-123 Includes items 1-40 HEATER MOUNTING KIT 222-269 NO. PART NO. DESCRIPTION Required to convert Model 222-268 Cold Sprayer to a heated 223-586 30:1 PRESIDENT PUMP unit. The heater is not included in this kit and must be ordered See 306-981 for parts separately, by desired voltage (see page 18).

  • Page 18: Accessories

    Accessories USE GENUINE GRACO PARTS AND ACCESSORIES AIR LINE LUBRICATOR GROUNDED NYLON FLUID HOSE 250 psi (17.5 bar) MAXIMUM WORKING PRESSURE 3000 psi (210 bar) MAXIMUM WORKING PRESSURE 214-848 1/2 npt inlet and outlet Part No. Length Thd. Size 214-849 3/4 npt inlet and outlet 214-700 3/16”...

  • Page 19: Mounting Dimensions

    222–268 and 221–123; 100 psi air, at 60 cpm. Sound level measured per ISO 3744–1981. In most cases the hose is the limiting factor to the temperature factor to the temperature rating. For high- er temperature applications, contact Graco or your lo- cal distributor for additional information. PTFE...

  • Page 20: Warranty

    Graco distributor to the original purchaser for use. As purchaser’s sole remedy for breach of this warranty, Graco will, for a period of twelve months from the date of sale, repair or replace any part of the equipment proven defective.
