DEMO MANUAL DC1555A
PARTS LIST
ITEM QUANTITY REFERENCE
Required Circuit Components
1 3 CLD1, CLD2, CLD3
2 0
3 0
4 0
5 2
6 1
7 1
8 0
9 0
10 0
11 4 E1, E2, E6, E7
12 4 E3, E4, E5, E8
13 3 JP1, JP2, JP3
14 1
15 0
16 1 R1 (Bal to #1608A)
17 1
18 1
19 1
20 1
21 3 XJP1, XJP2, XJP3
22 4
4
Current Limiting, Diode, SOD-80
C1 (OPT) Capacitor, X5R, 4.7μF , 50V, 20%, 1210
C2 (OPT) Capacitor, Alum, 47μF , 35V, 10%, OSCON-CE-6.3
C3 (OPT) Capacitor, X5R, 10μF , 25V, 10%, 1210
D1, D2 LED, GRN
D3 LED, RED
D4 Diode, 75V/200mW, SOD-523
D5 (OPT) Zener Diode, 15V, SOD-523
D6 (OPT) Zener Diode, 20V, POWERDI-123
D7 (OPT) Zener Diode, 40V, POWERDI-123
Turret, Testpoint 0.094"
Turret, Testpoint 0.063"
Headers, Sgl. Row, 3 Pins, 2mm Ctrs.
Q1 Dual N-Channel, 30V, SO-8
Q2 (OPT) Dual N-Channel, Low Current, SOT-563
Resistor, Chip, 1M, 0.06W, 1%, 0603
R2 Resistor, Chip, 54.9k, 0.06W, 1%, 0603
R3 Resistor, Chip, 36.5k, 0.06W, 1%, 0603
R4 Resistor, Chip, 510k, 0.06W, 5%, 0603
U1 IC, Over/Under/RevV/RevI Protection, SC8
Shunt, 2mm Ctrs.
Stand-Off, Nylon, 0.25" Tall
DESCRIPTION MANUFACTURERS PART NUMBER
Central Semi. Corporation, CCLM2000
Taiyo Yuden, UMK325BJ475MM-T
Sanyo, 35CE47AX
Taiyo Yuden, TMK325BJ106KM
Panasonic, LN1351CTR
Panasonic, LN1251CTR
Diodes Inc., 1N4148WT
Diodes Inc., BZT52C15T #PbF
Diodes Inc., DFLT20A #PbF
Diodes Inc., DFLT40A #PbF
Mill Max 2501-2-00-80-00-00-07-0
Mill Max 2308-2-00-80-00-00-07-0
Samtec, TMM-103-02-L-S
Vishay, SI4230DY-T1-GE3
Diodes Inc., 2N7002V-7
Vishay, CRCW06031M00FKEA
Vishay, CRCW060354K9FKEA
Vishay, CRCW060336K5FKEA
Vishay, CRCW0603510KJNEA
Linear Technology Corporation, LTC4365CTS8
Samtec, 2SN-BK-G
Keystone, 8831(Snap On)
