About the SD188ES/SD188EM
Demonstration Board
The AMD
exceptionally small, low-cost product for demonstration of the AMD Am188™ES
and Am188™EM microcontrollers. See page ix for a block diagram of the board.
The SD188ES/SD188EM demonstration board is a stand-alone evaluation
platform for the Am188ES or Am188EM microcontroller. The Am188ES and
Am188EM microcontrollers integrate peripherals such as 12 chip-select
controllers, serial controllers, 32 programmable I/Os, three timers, an interrupt
controller, and watchdog timer to increase system functionality while reducing
overall cost. The memory controller supports a glueless connection to SRAM,
EPROM, Flash memory, and pseudo-static RAM. The Am188ES and Am188EM
microcontrollers also feature an innovative bus design that frees the processor to
run at nearly twice the speed of standard 80C188 processors while using
commodity memory devices.
The SD188ES/SD188EM demonstration board is designed with a 104-pin Am188
expansion interface that provides access to the Am188ES and Am188EM
microcontrollers signals. The Am188 expansion interface facilitates prototyping
with external devices by using the SD188ES/SD188EM demonstration board as
the minimal system core of a design.
The SD188ES/SD188EM demonstration board highlights the Am188ES and
Am188EM microcontrollers' serial ports, glueless interface to SRAM and Flash
memory, and the expansion interface to peripheral attachments. A complete
description of the board can be found in Chapter 2, "Demonstration Board
Functional Description".
SD188ES/SD188EM Demonstration Board User's Manual
®
SD188ES/SD188EM Demonstration Board is designed as an
vii

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SD188ES and is the answer not in the manual?

Questions and answers

Summary of Contents for AMD SD188ES

  • Page 1 80C188 processors while using commodity memory devices. The SD188ES/SD188EM demonstration board is designed with a 104-pin Am188 expansion interface that provides access to the Am188ES and Am188EM microcontrollers signals. The Am188 expansion interface facilitates prototyping with external devices by using the SD188ES/SD188EM demonstration board as the minimal system core of a design.
  • Page 2 Theory of Operation The SD188ES/SD188EM demonstration board demonstrates the basic processor functionality and features of the Am188ES and Am188EM microcontrollers, and the simplicity of their system design. As a stand-alone platform, the board enables you to test the Am188ES and Am188EM microcontrollers’ performance and functionality.
  • Page 3 DB-9 Level Converter Connector Circuitry Power & Ground RS-232 Serial Port 5.5-mm DB-9 Level Converter Barrel Connector* Connector Circuitry* *Second asynchronous serial port implemented only with Am188ES microcontroller Figure 0-1. SD188ES/SD188EM Demonstration Board Block Diagram SD188ES/SD188EM Demonstration Board User’s Manual...
  • Page 4 Chapter 3, “Product Support” provides information on reaching and using the AMD Corporate Applications technical support services, product information available through AMD’s World Wide Web and FTP sites, and support tools for the embedded E86 family. Appendix A, “Layout Diagram, Schematics, and Board Bill of Materials” contains a board layout drawing along with schematics and a Bill of Materials (BOM) for the SD188ES/SD188EM demonstration board.
  • Page 5 • Am186™ and Am188™ Family Instruction Set Manual Advanced Micro Devices, order number 21267 • FusionE86 Catalog Advanced Micro Devices, order number 19255 • For current application notes and technical bulletins, see our World Wide Web page at http://www.amd.com. SD188ES/SD188EM Demonstration Board User’s Manual...
  • Page 6 Documentation Conventions The Advanced Micro Devices SD188ES/SD188EM Demonstration Board User’s Manual uses the conventions shown in Table 0-1 (unless otherwise noted). These same conventions are used in all E86 family support product manuals. Table 0-1. Notational Conventions Symbol Usage Boldface...
  • Page 7 Software User’s Manual included in your kit. For information on how to: • Connect the SD188ES/SD188EM demonstration board to a PC, see page 1-2 • Invoke the E86MON software, see page 1-4 • Troubleshoot installation problems, see page 1-5 • Locate related sources of information, see page 1-6...
  • Page 8 Connecting to a PC Follow the steps below to connect the SD188ES/SD188EM demonstration board to your PC. Installation Requirements The items listed below are necessary to install and run the SD188ES/SD188EM demonstration board: • PC with an available COM port ®...
  • Page 9 SD188ES/ SD188EM demonstration board 3. Connect the power supply to the barrel connector on the SD188ES/SD188EM demonstration board. 4. Apply power to the board by connecting the power supply to an electrical outlet.
  • Page 10 7. To display the version of the E86MON software and the commands available, type ? and press Enter. For detailed information on using the E86MON software, refer to the E86MON Software User’s Manual included in your manual. SD188ES/SD188EM Demonstration Board User’s Manual...
  • Page 11 There is a problem you Contact the AMD Corporate Applications cannot resolve. technical support services. (See Chapter 3, "Product Support" for phone numbers and more information.) SD188ES/SD188EM Demonstration Board User’s Manual...
  • Page 12 Software User’s Manual • Problems with the board or the E86MON software, see Chapter 3,“Product Support” • SD188ES/SD188EM demonstration board layout and schematics, see Appendix A,“Layout Diagram, Schematics, and Board Bill of Materials” • the Am188ES microcontroller see the Am186™ES and Am188™ES Microcontrollers Data Sheet •...
  • Page 13: Table Of Contents

    The SD188ES/SD188EM demonstration board was designed to meet the needs of customers working with the Am188ES and Am188EM microcontrollers. Read the following sections to learn more about the SD188ES/SD188EM demonstration board hardware: • “Layout and Placement” on page 2-2 •...
  • Page 14: Layout And Placement

    Layout and Placement The design of the SD188ES/SD188EM demonstration board emphasizes ease of use and small size. Refer to Figure 2-1 on page 2-3 for board layout and component placement. The SD188ES/SD188EM demonstration board has the Flash and SRAM memory devices (U4 and U3) directly below the processor.
  • Page 15 1.On the SD186ES demonstration board, P1 is asynchronous serial port 0; P0 is asynchronous serial port 1. 2.On the SD186EM demonstration board, P1 is an asynchronous serial port; P0 does not exist. Figure 2-1. SD188ES/SD188EM Demonstration Board Layout SD188ES/SD188EM Demonstration Board User’s Manual...
  • Page 16: Am188Es And Am188Em Microcontroller Implementation

    Am188ES and Am188EM Microcontrollers Implementation The SD188ES/SD188EM demonstration board supports the AMD Am188ES and Am188EM microcontrollers. The board is shipped with either an Am188ES or Am188EM microcontroller that operates at 40 MHz. Although not supported by the on-board crystal, the Am188ES and Am188EM microcontrollers are also available in 20-, 25-, and 33-MHz operating frequencies.
  • Page 17 Chip-Select CTS0/ENRX0 Interface DEN/DS Unit Unit HOLD TXD1 Asynchronous HLDA RXD1 Serial Port 1 S6/LOCK/ RTS1/RTR1 CLKDIV2 CTS1/ENRX1 LCS/ONCE0 PCS6/A2 A19-A0 PCS5/A1 MCS3/RFSH AO15-AO8 MCS2-MCS0 PCS3-PCS0 AD7-AD0 UCS/ONCE1 RFSH2/ADEN Figure 2-2. Am188ES Microcontroller Block Diagram SD188ES/SD188EM Demonstration Board User’s Manual...
  • Page 18 DT/R Unit Chip-Select Control Interface Unit Registers Unit HOLD HLDA Synchronous Serial Interface CLKDIV2 SCLK SDATA LCS/ONCE0 PCS6/A2 SDEN0 SDEN1 A19-A0 PCS5/A1 MCS3/RFSH AO15-AO8 MCS2-MCS0 PCS3-PCS0 AD7-AD0 UCS/ONCE1 RFSH2/ADEN Figure 2-3. Am188EM Microcontroller Block Diagram SD188ES/SD188EM Demonstration Board User’s Manual...
  • Page 19: Rom Space

    ROM Space The SD188ES/SD188EM demonstration board contains on-board ROM space for use by the E86MON software and application code. This ROM space is implemented as one Am29F010 70-ns Flash memory device. This Flash memory device is mapped to the upper region of addressable memory at E0000h to FFFFFh.
  • Page 20: Rs-232 Serial Ports

    RS-232 Serial Ports The ES version of the SD188ES/SD188EM demonstration board provides two on- board RS-232 serial ports (P0, P1) that are directly driven by the Am188ES microcontroller. The serial ports are equipped with DB-9 DCE connectors. The pin assignment for the DB-9 connectors is shown in Figure 2-4 on page 2-9.
  • Page 21 The SD188EM serial port does not support RTS0 and CTS0 in hardware. Instead, these signals are connected to PCS3 and PCS2. The SD188EM demonstration board has only one asynchronous serial port. The serial port is connected to P1. Figure 2-4. DB-9 Serial Connector Pinout SD188ES/SD188EM Demonstration Board User’s Manual...
  • Page 22: Clock And Reset Logic

    The pinout of the expansion interface for the SD188ES is shown in the figures that follow. NOTE: The pinout of the expansion interface is identical for both the SD188ES and SD188EM demonstration boards except for the four pins shown in Table 2-2.
  • Page 23 ARDY TMROUT1 8 TMRIN1 7 TMRIN0 6 NC 5 TMROUT0 4 VCC 3 RESET 2 GND 1 *Refer to Table 2-2 for a description of these pins. Figure 2-5. Am188 Expansion Interface Pinout (J2) 2-11 SD188ES/SD188EM Demonstration Board User’s Manual...
  • Page 24 PCS2 5 INT0 PCS3 4 INT1 PCS5 3 INT2 PCS6 2 BHE 1 HOLD 0 GND *This pin is connected to a No Connect pin on the SRAM. Figure 2-6. Am188 Expansion Interface Pinout (J3) SD188ES/SD188EM Demonstration Board User’s Manual 2-12...
  • Page 25: Pio Activity Led Indicators

    PIO Activity LED Indicators The SD188ES/SD188EM demonstration board uses on-board LED indicators to show activity on the upper eight programmable I/O (PIO) signals from the Am188ES or Am188EM microcontroller. Table 2-3 shows which PIO signal is represented by each LED.
  • Page 26: Power Supply

    Power Supply When used as a stand-alone board, the SD188ES/SD188EM demonstration board requires an input power supply of 5.0 V DC, ±5%, 250 mA. When adding components to the SD188ES/SD188EM demonstration board via the expansion interface, additional power may be necessary.
  • Page 27 This chapter contains information on: • Reaching and using the AMD Corporate Applications technical support services, on page 3-2 • Product information available through AMD’s World Wide Web and FTP sites, on page 3-4 • Support tools for the E86 family, on page 3-5...
  • Page 28 In Europe and the UK, send mail to: euro.tech@amd.com Online Support AMD offers technical support on our WWW site, and through our bulletin board services. See “Product Support” on page 3-4 for more on what our WWW and FTP sites have to offer.
  • Page 29 Far East Asia Fax: (852) 2956-0599 Germany Tel.: 089 450 53199 UK and Europe Tel.: 44-(0) 1276-803-299 Fax: 44-(0) 1276-803-298 Toll-Free Numbers Country Number USA and Canada (800) 222-9323 France 0590-8621 Italy 1678-77224 Japan 0031-11-1163 SD188ES/SD188EM Demonstration Board User’s Manual...
  • Page 30 A subset of the AMD WWW pages, the embedded processor pages are frequently updated and include general product information, technical documentation, and support and tool information. To access these pages, go to the AMD home page at http://www.amd.com and click on “Embedded Processors” or access the pages directly at http://www.amd-embedded.com.
  • Page 31 FTP site. To download the software, ftp to ftp.amd.com and log on as “anonymous” using your e-mail address as a password. Or via your web browser, go to ftp://ftp.amd.com. Software relating to the E86 family can be found in the /pub/epd/e86/ directory.
  • Page 32 SD188ES/SD188EM Demonstration Board User’s Manual...
  • Page 33 Appendix A Layout Diagram, Schematics, and Board Bill of Materials This appendix contains a board layout diagram, schematics, and the bill of materials (BOM) for the SD188ES/SD188EM demonstration board. SD188ES/SD188EM Demonstration Board User’s Manual...
  • Page 34 1.On the SD186ES demonstration board, P1 is asynchronous serial port 0; P0 is asynchronous serial port 1. 2.On the SD186EM demonstration board, P1 is an asynchronous serial port; P0 does not exist. Figure A-1. SD188ES/SD188EM Demonstration Board Layout SD188ES/SD188EM Demonstration Board User’s Manual...
  • Page 35 Schematics The SD188ES/SD188EM demonstration board schematics have been blocked out to separate functionality of the design onto separate pages as follows: • Page A-4 contains the power connector and decoupling capacitors • Page A-5 contains the Am188ES or Am188EM microcontroller, clock, and reset circuitry •...
  • Page 36 SD188ES/SD188EM Demonstration Board User’s Manual...
  • Page 37 SD188ES/SD188EM Demonstration Board User’s Manual...
  • Page 38 SD188ES/SD188EM Demonstration Board User’s Manual...
  • Page 39 SD188ES/SD188EM Demonstration Board User’s Manual...
  • Page 40 SD188ES/SD188EM Demonstration Board User’s Manual...
  • Page 41 SD188ES/SD188EM Demonstration Board User’s Manual...
  • Page 42 SD188ES/SD188EM Demonstration Board User’s Manual A-10...
  • Page 43 Board Bill of Materials (BOM) Table A-1. SD188ES/SD188EM Demonstration Board BOM Description MFG1 Part No 1 22 MFd, SMT, C case, 20 V 1.0 MFd, SMT, 16 V C13, C16, C17, 0.1 MFd, SMT, 20 V C24-C29 15 PFd, SMT, 16 V...
  • Page 44 SD188ES/SD188EM Demonstration Board User’s Manual A-12...
  • Page 45 3-2 clock logic, 2-10 expansion interface, 2-10 clock rates supported, 2-10 J2 pinout, 2-11 COM ports, J3 pinout, 2-12 See ports connecting demo board to PC, 1-2 connectors DB-9, 1-3 conventions documentation, xii Index-1 SD188ES/SD188EM Demonstration Board User’s Manual...
  • Page 46 2-14 CR3–CR10, 1-4 polarity, 2-14 flashing incorrectly, 1-5 to the board, 1-3 indicators, 2-13 product support no power, 1-5 FTP site, 3-5 PIO indicators, 2-13 third party (FusionE86), 3-5 WWW site, 3-4 SD188ES/SD188EM Demonstration Board User’s Manual Index-2...
  • Page 47 3-4 power supply, 2-14 technical support, 3-2 reset logic, 2-10 ROM space, 2-7 RS-232 serial port, 2-8 schematics, A-3 Y1 location on board, 2-2 SRAM, 2-7 technical support, 3-1 serial ports, 1-3 Index-3 SD188ES/SD188EM Demonstration Board User’s Manual...
  • Page 48 SD188ES/SD188EM Demonstration Board User’s Manual Index-4...
