hepco & becker 502937 00 01 Quick Start Manual

Engine guard for bmw f 800 r 2014-/2015-

Advertisement

Motorschutzbügel/ Engine guard
BMW F 800 R
bis Baujahr 2014 / up to date of manufacture 2014
502
Artikel Nr.: / Item-no.:
BMW F 800 R
ab Baujahr 2015 / from date of manufacture 2015
501
Artikel Nr.: / Item-no.:
INHALT
CONTENTS
1
705.526HB
Motorschutzbügel links
1
705.527HB
Motorschutzbügel rechts
1
Schraubensatz:
1
Inbusschraube M 10 x 140
1
Inbusschraube M 10 x 150
2
Inbusschraube M 10 x 100
4
U-Scheibe ø10,4
1
Stahldistanz ø18 x ø13 x 68mm
1
Stahldistanz ø18 x ø13 x 83mm
1
Stahldistanz ø18 x ø13 x 15mm
1
Stahldistanz ø18 x ø13 x 10mm
1
705.526HB
Engine guard, left
1
705.527HB
Engine guard, right
1
Screwkit:
1
allen screw M 10 x 140
1
allen screw M 10 x 150
2
allen screw M 10 x 100
4
washer ø10,4
1
steel spacer ø18 x ø13 x 68mm
1
steel spacer ø18 x ø13 x 83mm
1
1steel spacer ø18 x ø13 x 15mm
1
1steel spacer ø18 x ø13 x 10mm
WICHTIG
IMPORTANT
Beachten Sie die in Ihrem Land geltenden Zulassungsbestimmungen.
Für den Bereich der BRD gilt: Ein Eintrag in die Fahrzeugpapiere ist nicht erforderlich.
Die Voraussetzung für die Montage ist natürlich eine gewisse technische Erfahrung. Wenn Sie sich nicht sicher sind,
wie man eine bestimmte Arbeit ausführt, sollten Sie diese Ihrer Fachwerkstatt überlassen. Ziehen sie alle zugänglichen
Schrauben zuerst nur locker an. Nachdem alles montiert ist, werden die Schrauben dann auf das entsprechende
Anzugsmoment festgezogen. Dadurch wird sichergestellt, dass das Produkt spannungsfrei angebaut ist. Anzugsmomente
beachten! Nach der Montage alle Verschraubungen auf festen Sitz kontrollieren!
Zur Montage ist eine zweite Person hilfreich.
Of course, the assembly requires a certain technical experience. If you are not sure how to execute a determined action,
you should ask your local distributor to do it. First, tighten all screws only loosely. After mounting all parts, the screws
should be tightened to the torque specified. This guarantees, that the product is mounted without tension. Observe
the tightening torques of the manufacturer! Control all screw connections after the assembling for tightness!
To mount this guard, a second person is helpful.
