JABSCO 29200-0120 Manual

ELECTRIC FLUSH PUMP
FEATURES
• Directly replaces Manual Pump Assembly
• Easy to install
• Fits all Jabsco manual toilets and
others with optional adapters
• Simple to operate
• Built-in macerator
SPECIFICATIONS
Ports: Inlet - 3/4" Hose Barb; Discharge - Attach
manual pump 11/2" discharge elbow
Motor: Permanent magnet type with ball bearings
on double ended stainless steel shaft
Pumps: Two flexible impeller pumps mounted on
opposite ends of double ended motor
Weight: 71/2 lb (3,4 kg)
Dimensions: 10-1/2" (267 mm) high, 3-3/8" (86 mm) wide,
5-7/8" (149 mm) deep, 40" (1000 mm) wire leads
APPLICATION
The Jabsco Electric Flush Pump will convert any Jabsco or
PAR manual toilet to electric operation. It is assembled at
the factory to fit the 29090-Series and 29120-Series toilets
which have been in production since 1987. The flush pump
assembly simply replaces the entire manual pump assembly
and screws directly to the toilet base. In addition to Jabsco
& PAR toilets, the flush pump will also fit the Brydon Boy,
Mansfield (Sealand) 751, Raske & Van der Meyde RM69, and
Taiwan Magnetics TMC 999 toilet models.
In order to install the Flush Pump on the following listed
toilet models, the indicated optional mounting flange must
be installed on the pump assembly.
Pump Mounting
Toilet Model Configuration
PAR
BRYDON BOY
GROCO HC
Mansfield 750
GROCO HE
GROCO HF Equilateral Triangle
Raritan Compact
Raritan PH & PH II
Sealand 752 Square Pattern
Wilcox Crittenden
Head Mate 1460 C
Wilcox Crittenden Square Pattern
Winner R4042C*
* The Wilcox Crittenden Flange Kit includes a 90° discharge elbow
and joker valve which must be used in place of the original elbow
and joker valve. The Winner toilet requires minor repositioning of
the discharge plumbing because the new discharge elbow will be
lower and about 4 inches further from the toilet bowl.
Models 29200-0120
Flush Pump Mounting
Flange Adaptor Kit
3 Hole 29060-0000
Triangle
2 Hole 29125-0000
3 Hole 29080-0000
4 Hole 29110-0000
4 Hole 29128-0000
29200-0240
The pump may be installed on toilets which are mounted as
high as 2 feet above the vessel's waterline or on toilets below
the waterline if the total cumulative discharge head does not
exceed 6 feet. It will fit toilets with either a compact size bowl or
large household size bowl. Generally, the pump requires no
modification or additions to the existing plumbing which services
the manual pump assembly. However, if the discharge hose
rises and falls repetitively and the total of all rising segments
(when added together) exceeds 6 feet, it should be re-routed so
the total cumulative rise is less than 6 feet. If this can not be
done, the electric flush pump should not be installed.
INSTALLATION
WARNING
Flood hazard. If toilet is installed below the
!
waterline or may be below the waterline at any
angle of heel or trim, it must be installed with
properly positioned vented loops. Failure to do
so can result in flooding which can cause loss
of property and life.
The pump is assembled at the factory with a base mounting
flange (macerator housing) which fits the 29090-Series and
29120-Series toilets. If the pump is to be installed on a PAR
59128-Series (Brydon Boy), Mansfield (Sealand) 751, Raske
& Van Der Meyde RM69, Simpson Lawrence 444, orTaiwan
Magnetics TMC 999, it is necessary to replace the four hole
mounting flange with one of the optional mounting flanges listed
in the Application section.
To change the mounting flange, remove the four screws (on
bottom of pump assembly) which secure the mounting flange to
the waste pump body. Note the relative position of the long and
short screws.
12 Volt
24 Volt
