EVAPORATOR, ICE CUTTER GRID AND WATER PARTS
For Models: GI15NDXTQ1, GI15NDXTB1,GI15NDXTS1
(White)
Illus.
Part
No.
No.
1 W10159841 Valve, Complete
2
2217286 Tube, Plastic
3
488208 Screw
4
2185523 Dispenser, Water
5
W10218037
6
2313705 Pump, Drain
7
2313851 Tube,Reservoir
8
2172593 Tube, Water Fill
9
488660 Nut, Speed
10
836667 Spacer
11
2208539 Fastener,
12
489443 Screw
13
2185625 Reservoir,
14
2185626 Tube
15
2313890 Hose, Overflow
16
2313604 Guide−Ice, Grid
17
2313603 Bracket, Front
18
2313602 Bracket, Side
19
2185681 Harness, Grid
20 W10136146 Tube
21
2310169 Wire Assembly
26
3400886 Screw 8−18 x 1 1/4
28
2313637 Grid Assembly
29
2174754 Wire, Grid Cutter
30
2185570 Cover, Grid
31
8281228 Thumbscrew
32
2324334 Reservoir, Water
33
3400884 Screw 8−18 x 5/8
34
2185696 Cap, Drain
35
3400909 Nut, Push−In
(Black) (Stainless Steel)
DESCRIPTION
Water
Evaporator
Pump
Pushnut
Water Slide
and Rear
Left and Right
Valve
(Complete)
4
W10165835
