Parts List - Code 3 C3100 Installation & Operation Manual

Installation Procedure:
Driver Side continued:
5. Install opposite sides of the Hook and Pile pads on
the top of the cross frame rail where the bracket is to
be installed.
6. Pushing the short leg upward against the splash
guard - re insert the L bracket over the frame member
and seat the hook and pile connecting pads into each
other.
7. Insert tab of clamp bracket into L bracket slot. The
clamp bracket must be manuvered under manifold
lines.
8. Rotate the clamp bracket over the bottom of the
cross frame and seat over studs on L bracket..
9. Install (2) 1/4- 20 nuts over studs on L bracket and
tighten while maintaining upward pressure on the
clamp assembly.

Parts List:

part no:
1. T56186
2. T56187
3. T06139
4. T14563
5. T03440
6. T03432
Description:
L speaker bracket
Clamp bracket
Keps Nut 1/4-20
Carriage Bolt 1/4-20
Loop Strip
Hook Strip
Notes:
3
FWD
Qty:
1
1
2
2
2
2
