INSTALLATION &
OPERATION
MANUAL
2015 FORD F-150
C3100 SPEAKER INSTALLATION
2015 FORD F-150 NO-DRILL INSTALLATION OF
Page No:
1.
2.
3.
4.
Preparation for Installation:
Hardware provided for this installation will help prevent galvanic corro-
sion from taking place due to dissimilar metals.
1. The mounting of C3100 speaker using the clamp-on design bracket will avoid the need
for drilling into the aluminum body of the new Ford F150 truck.
2. The Loop and Pile Pads at the top of the assembly will prevent lateral movement of the
unit once the bracket system is tightened into position.
IMPORTANT:
C3100 SPEAKER (S)
Table of Contents:
Description:
Pre-installation preparation
Installation instructions
Installation notes
Warranty Information
Read all instructions and warnings before installing and using.
This manual must be delivered to the end user of this equipment.
INSTALLER:
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Code 3 C3100
Summary of Contents for Code 3 C3100
- Page 1 Hardware provided for this installation will help prevent galvanic corro- sion from taking place due to dissimilar metals. 1. The mounting of C3100 speaker using the clamp-on design bracket will avoid the need for drilling into the aluminum body of the new Ford F150 truck.
- Page 2 Locate areas under the truck front end at the cross member as pictured. Two speaker bracket systems can be mounted on this cross member. View looking up Installation Procedure: mark area for at Passenger side Passenger Side: pads to be in- of truck frame.
- Page 3 Installation Procedure: Driver Side continued: 5. Install opposite sides of the Hook and Pile pads on the top of the cross frame rail where the bracket is to be installed. 6. Pushing the short leg upward against the splash guard - re insert the L bracket over the frame member and seat the hook and pile connecting pads into each other.
- Page 4 *Code 3, Inc. reserves the right to repair or replace at its discretion. Code 3, Inc. assumes no responsibility or liability for expenses incurred for the removal and /or reinstallation of products requiring service and/or repair.;...
