You can test your request at any time by clicking on the refresh
-
Variable configuration:
For each request from a Modbus slave, you can add, modify or delete a variable.
To add a new variable, click directly on the address of the first register of the variable in the
query register representation.
Next, give the variable a name and a type.
The type of variable defines both its format and size. The following is a summary table of the
available variable types.
Label
U8
S8
U16
S16
U32
S32
U64
WebdynSunPM – User guide — Version 1.0
Format Size
Integer 8 bits
Integer 8 bits
Integer 16 bits
Integer 16 bits
Integer 32 bits
Integer 32 bits
Integer 64 bits
USER GUIDE – WebdynSunPM
button.
Signed
No
Yes
No
Yes
No
Yes
No
