5500 and 5400 Series Surface
Nonmetallic Raceway Systems
INSTALLATION INSTRUCTIONS
Installation Instruction No.: 41590R5 – Updated July 2005
5500BD3
8
3
2
Miter Saw
Use una sierra de ingletes
Scie à onglet
* Not supplied.
** No se incluye(n).
*** Non fournis.
5500C
6
1
12
13
Recommended Cutting Tools & Fasteners*
Herramientas de corte y sujetadores recomendados**
Outil de coupe et attaches recommandés***
Use a #8 [5/16", 7.9mm Head Size] Pan Head Screw or equivalent.
Use un tornillo de cabeza redonda N° 8 (con cabeza de 7.9mm
[5/16"] o equivalente.
Utilisez une vis BER n°8 (tête do 7,9mm [5/16 po]) ou équivalent.
Wiremold Electrical Systems conform to and should be
installed and properly grounded in compliance with
requirements of the current National Electrical Code,
Canadian Electrical Code or codes administered by
local authorities.
All electrical products may represent possible shock or fire
hazard if improperly installed or used. Wiremold electrical
products are UL listed. Made for interior use only and
should be installed in conformance with current local
and/or the National Electrical Code.
5400TB
14
11 15
5400C
16
5
3
2
4
5400TC
7
9
