10-12 DK55

ADJUSTING CLUTCH PEDAL

(1) Clutch Pedal (3) Clutch Lever
(2) Clutch Rod (4) Clutch Rod 2
(A) Length Of Clutch Rod
20 ~ 30 mm
Proper clutch
(0.8 ~ 1.2 in.)
pedal free travel(A)
on the pedal
1. Stop the engine and remove the key.
2. Slightly depress the clutch pedal and
measure free travel at top of pedal
stroke.
3. If adjustment is needed, loosen the lock
nut, remove the clevis pin and adjust
the rod length within acceptable limits.
4. Retighten the lock nut and split the
cotter pin.

ADJUSTING BRAKE PEDAL

069OA18A
(1) Turn Buckle
(2) Lock Nuts
(A) 25 to 40mm(0.98 to 1.57in)
To avoid personal injury:
Stop the engine and chock the
wheels before checking brake
pedal.
1. Release parking brake.
2. Slightly depress the pedals and mea-
069OA19A
3. When adjustments are needed, loosen
(3) Brake Pedal
(4) Brake Rod
4. Re-tighten the lock nuts.
CAUTION
25 ~ 40 mm
(0.98 ~ 1.57 in.)
Proper
on the pedal.
brake pedal
Keep the free travel
free travel
in the right and left
brake pedals equal.
sure the free travel at the top of the
pedal stroke.
the locking nut and turn the turnbuckle
until the rod length is at the desired
and acceptable limit.
