Instructions for installation and use

1.4. ALASKA VIEW parts list

No. of items
Base frame
1 Base frame
1 Base frame
1 Base frame
Wall elements
3 A/A wall element with Multiclip
4 A/A wall element
1 A/A electrical element with Multiclip
2 A/B wall element
1 A/B wall element with Multiclip
1 A/B ventilation element with Multiclip
1 Element above glass front
Ceiling elements
1 A/B ceiling element
2 A/B ceiling element
1 A/B ceiling element
Corner posts
2 90º corner post with slot for glass
2 90° corner post with Multiclip
Support slats
4 Roof support slat
2 Bench support slat
2 Bench support slat
1 Bench support slat
4 Roof support slat
2 Mounting rail for bench screen
Name
p. 6/34
Dimensions
198 x 9 x 4 cm
198 x 9 x 4 cm
204 x 9 x 4 cm
193 x 48 x 4 cm
193 x 48 x 4 cm
193 x 48 x 4 cm
193 x 48 x 4 cm
193 x 48 x 4 cm
193 x 48 x 4 cm
192 x 10.1 x 4 cm
194 x 50 x 4 cm
194 x 48 x 4 cm
194 x 49 x 4 cm
202 x 6 x 6 cm
193 x 6 x 6 cm
192 x 4 x 4 cm
120 x 4 x 4 cm
58 x 4 x 4 cm
100 x 4 x 4 cm
196 x 4 x 1.2 cm
26 x 4 x 4 cm
