Electrical Requirements
Electrical Shock Hazard
Plug into a grounded 3 prong outlet.
Do not remove ground prong.
Do not use an adapter.
Do not use an extension cord.
Failure to follow these instructions can result in death,
fire, or electrical shock.
Observe all governing codes and ordinances.
A 120 V, 60 Hz, AC only, 15 or 20 A electrical supply with a
fuse or circuit breaker.
A time-delay fuse or time-delay circuit breaker.
A separate circuit serving only this microwave oven.


The clock is a 12-hour (12:00-11:59) clock. Touch SETUP/CLOCK,
enter time, then touch SETUP/CLOCK or the Start control.
With the microwave oven in Standby mode, touch the Timer
control, enter time, then touch the Timer control or the Start
control. Cook functions may be entered while the Timer is
counting down. To cancel timer, touch Timer control while the
Timer countdown is active in the display.
Control Lock
Activate to avoid unintended start. Touch and hold the Cancel
keypad for about 3 seconds until 2 tones sound and the
CONTROL LOCKED appears in the display. When locked,
touching any button on the keyboard (except for the hood control
buttons and Cancel) will not work. Repeat to unlock control.
Vent Fan
Press the Vent Fan keypad once for High setting. You may press
this keypad repeatedly and choose a different speed. There are
four available speeds HIGH--->MEDIUM--->MEDIUM LOW--LOW-
-->OFF. Choose the speed you want.
To keep the microwave oven from overheating, the auto hood fan
will automatically turn on at high speed if the temperature from the
range or cooktop below the microwave oven gets too hot. When
this occurs, the hood fan cannot be turned off.
Vent Light
Pressing Vent Light keypad adjusts the vent light setting among


For all cord connected appliances:
The microwave oven must be grounded. In the event of
an electrical short circuit, grounding reduces the risk of
electric shock by providing an escape wire for the electric
current. The microwave oven is equipped with a cord
having a grounding wire with a grounding plug. The plug
must be plugged into an outlet that is properly installed
and grounded.
Improper use of the grounding plug can
result in a risk of electric shock. Consult a qualified
electrician or serviceman if the grounding instructions are
not completely understood, or if doubt exists as to whether
the microwave oven is properly grounded.
Do not use an extension cord. If the power supply cord is
too short, have a qualified electrician or serviceman install
an outlet near the microwave oven.
This device complies with Part 18 of the FCC Rules.
Press SETUP/CLOCK repeatedly, there are various options/setting
may be adjusted:
1-Clock; 2-Sound; 3-Scrolling Speed; 4-Language; 5-Filter Reset;
6-Fan Timer; 7-Demo Mode; 8-Factory Reset.
Sound (Tones)
Keypad tones and volume can be adjusted. Press SETUP/CLOCK
to reach the Sound submenu.
1. Button Tones On and Off: Press 1-On 2-Off
2. Volume: Press 1-Low, 2-Med, 3-High
Pressing the Start keypad, pressing the SETUP/CLOCK keypad
will save.
Scroll Speed
Scrolling speed options will be between Low, Medium and High
speeds. Press SETUP/CLOCK to reach the scrolling speed
submenu. Once you select speed, press start or SETUP/CLOCK
keypad will save.
There are two languages supported: English and French. Press
SETUP/CLOCK to reach the Language submenu. Once options
for language is selected you'll have two options. Press start or
SETUP/CLOCK keypad will save.
Filter Reset
Reset the filter status after replacing and/or cleaning the filters.
Touch SETUP/CLOCK to reach the Filter Reset submenu, and
activate reset.
