INSTALLATION INSTRUCTIONS
This product is suitable for use above electric or gas built-in ovens, and below non-vented electric or gas cooktops. This product is not
suitable for use below downdraft cooktops.
These installation instructions cover different models. The appearance of your particular model may differ slightly from the illustrations in
these Installation Instructions.
BUILT-IN MICROWAVE OVEN SAFETY
We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety
messages.
This is the safety alert symbol.
This symbol alerts you to potential hazards that can kill or hurt you and others.
All safety messages will follow the safety alert symbol and either the word "DANGER" or "WARNING."
These words mean:
WARNING
All safety messages will tell you what the potential hazard is, tell you how to reduce the chance of injury, and tell you what can
happen if the instructions are not followed.
W10111676
BUILT-IN MICROWAVE OVEN
24" (61.0 cm), 27" (68.6 cm), 30" (76.2 cm)
BUILT-IN MICROWAVE OVEN SAFETY.......................................... 1
INSTALLATION REQUIREMENTS ................................................... 2
Tools and Parts............................................................................... 2
Location Requirements................................................................... 2
Minimum Dimensions ..................................................................... 3
Product Dimensions ....................................................................... 4
Electrical Requirements .................................................................. 5
INSTALLATION INSTRUCTIONS ..................................................... 6
(24" [61.0 cm] Installation Only) ...................................................... 6
(27" [68.6 cm] or 30" [76.2 cm] Installation Only) ........................... 7
Complete Installation ...................................................................... 8
ASSISTANCE ..................................................................................... 8
Your safety and the safety of others are very important.
DANGER
Table of Contents
You can be killed or seriously injured if you don't immediately
follow instructions.
You can be killed or seriously injured if you don't follow
instructions.
Advertisement
Table of Contents
Related Manuals for KitchenAid KBMS1454S
Summary of Contents for KitchenAid KBMS1454S
-
Page 1: Table Of Contents
W10111676 24" (61.0 cm), 27" (68.6 cm), 30" (76.2 cm) Table of Contents BUILT-IN MICROWAVE OVEN SAFETY... 1 INSTALLATION REQUIREMENTS ... 2 Tools and Parts... 2 Location Requirements... 2 Minimum Dimensions ... 3 Product Dimensions ... -
Page 2: Installation Requirements
†®TORX is a registered trademark of Textron Innovations Inc. The microwave oven may be located in a cabinet, and/or above a built-in oven, or below the counter and/or below a non-vented cooktop. Check the opening where the microwave oven will be installed. -
Page 3: Minimum Dimensions
NOTE: The bottom of the cooktop may be sunk into the counter and lower cabinet. The minimum 3" (7.6 cm) clearance must exist below the lowest point of the cooktop, and there must be no interference between any part of the cooktop (including any gas fittings) and the microwave oven. Minimum Dimensions... -
Page 4: Product Dimensions
INSTALLATION Min. 25 " (65.4 cm) Max. 28 " (73.0 cm) 18" (45.7 cm)* *Measurements include front facing of microwave oven. Depth measurement also includes door handle. 26 " (66.7 cm) 21 " (55.2 cm) A. Microwave oven B. Non-flush receptacle C. -
Page 5: Electrical Requirements
Electrical Requirements GROUNDING INSTRUCTIONS For all cord connected appliances: The microwave oven must be grounded. In the event of an electrical short circuit, grounding reduces the risk of electric shock by providing an escape wire for the electric current. The microwave oven is equipped with a cord having a grounding wire with a grounding plug. -
Page 6: Installation Instructions
1. Empty microwave oven of any loose items. 2. Using 2 or more people, slide the microwave oven all the way into the opening. 3. Center the microwave oven within the opening. Open the microwave oven door. -
Page 7: Install The Microwave Oven (27" [68.6 Cm] Or 30" [76.2 Cm] Installation Only)
C. Proper side bracket attachment 5. Tighten screws to secure the side bracket to the microwave oven. 6. Repeat steps 4 and 5 on the other side of the microwave oven. Install the Microwave Oven Plug into a grounded 3 prong outlet. -
Page 8: Complete Installation
All rights reserved. Complete Installation 1. Install the turntable in the microwave oven. 2. Check the operation of microwave oven by placing 1 cup (250 mL) of water on the turntable and programming cook time of 1 minute at 100% power.
