Push'n Scoot
Front Axle Replacement Kit
• Adult assembly is required.
• Tools needed: Pliers, hammer, scrap block of wood
• Follow these instructions to replace the front axles on your vehicle.
Please replace both front axles at the same time, even if only
one of the front axles shows wear or damage.
• If you have any questions or are missing a part, please call
Mattel Australia's Consumer Advisory Service at 1-800-800-812
(valid in Australia only).
Jeep
Model Number: 72607
®
™
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Fisher-Price Jeep Push'n Scoot 72607
Summary of Contents for Fisher-Price Jeep Push'n Scoot 72607
- Page 1 Jeep ® Push’n Scoot ™ Model Number: 72607 Front Axle Replacement Kit • Adult assembly is required. • Tools needed: Pliers, hammer, scrap block of wood • Follow these instructions to replace the front axles on your vehicle. Please replace both front axles at the same time, even if only one of the front axles shows wear or damage.
- Page 2 Replacement Parts “A” “B” “A” Front Axle 5 Cap Nuts* “B” Front Axle *One extra cap nut has been included for your convenience. Removing the Front Axles • Remove the two cap nuts from each front axle assembly. Use pliers to firmly squeeze the rim on a cap nut.
- Page 3 Removing the Front Axles Bushing Bushing Bushing Bushing Washer Washer Front Wheel Front Axles Front Wheel Cap Nut Cap Nut Washer Washer • Remove the front axle assemblies from the vehicle body. Discard the front axles and cap nuts only. Save all bushings, washers and the front wheels for re-assembly.
- Page 4 Cap Nut Wheel Spoke Side Up "A" Front Axle Scrap Block "A" Front "B" Front of Wood Washer Axle Axle • Identify and separate the "A" and "B" front axles. • Place the "A" front axle on a scrap block of wood. •...
- Page 5 Front Axle Assembly Vehicle Body "A" Marking "A" Front Axle Bushing • Lift the front end of the vehicle body and locate the side of the vehicle body marked "A". IMPORTANT! For proper wheel position, the "A" front axle assembly must be inserted into the hole in the vehicle body marked "A".
- Page 6 Mattel Australia Pty. Ltd. 658 Church Street Locked Bag #870 Richmond, Victoria 3121 Fisher-Price, Inc., a subsidiary of Mattel, Inc., East Aurora, New York 14052, U.S.A. ©2000 Mattel, Inc. All Rights Reserved. ® and ™ designate U.S. trademarks of Mattel, Inc.
