- Page 1 This Owner's Manual is provided and hosted by Appliance Factory Parts. FISHER PRICE H3427 Owner's Manual Shop genuine replacement parts for FISHER PRICE H3427 Find Your FISHER PRICE Ride On Parts - Select From 999 Models -------- Manual continues below --------...
- Page 2 Please read this manual and save it with your original sales receipt. Tools needed for assembly: Phillips Screwdriver, Adjustable Wrench (or Pliers) and Safety Scissors (all not included). Use only with a Power Wheels ® 12 Volt Lead Acid Rechargeable Battery and Power Wheels ®...
-
Page 3: Table Of Contents
• Use this vehicle ONLY outdoors. Most interior flooring can be repairs for a minimal charge. To find the authorized service center damaged by riding this vehicle indoors. Fisher-Price ® will not be nearest you, please visit us on-line at www.powerwheels.com... -
Page 4: B Warnings And Cautions
WARNINGS AND CAUTIONS ELECTRICAL HAZARD WARNING • Battery can fall out and injure a child if vehicle tips over. Always use battery clamp. • PREVENT FIRE - Never modify the electrical system. Alterations could cause a fire resulting in serious injury and could also ruin the electrical system. -
Page 5: C Parts
PARTS • If you experience a problem with this product, or are missing a part, please call us at 1-800-348-0751, rather than return this product to the store. • Please identify all parts before assembly and save all packaging material until assembly is complete to ensure that no parts are discarded. •... - Page 6 TABLE OF CONTENTS PARTS #8 x 1" Screw – 5 12 Volt Battery 12 Volt Charger #8-32 x 1.625" Screw – 2 Taillight Lens Set #10 x 1" Screw – 11 #8 Acorn Lock Nut – 2 Taillight Housing Set #10 x "...
-
Page 7: Parts Picture
TABLE OF CONTENTS PARTS PICTURE Note: Some parts shown are assembled on both sides of the vehicle. Parts Not Shown Vehicle Long Seat Belt Strap Steering Column Dash Spacer #8 x 1" Screw - 5 #8 x " Screw - 1 Hood Latch Headlight Lens Sport Bar... -
Page 8: Battery Charging
BATTERY CHARGING ELECTRICAL HAZARD CAUTION WARNING • Battery can fall out and injure a child if Use the charger in dry locations only. vehicle tips over. Always use battery clamp. • PREVENT FIRE About Thermal Fuses - Never modify the electrical system. Your Power Wheels 12 volt battery is equipped with a built-in Alterations could cause a fire resulting thermal fuse. -
Page 9: F Assembly
BATTERY CHARGING ASSEMBLY WARNING Children can be harmed by small parts, sharp edges and sharp points in the Battery vehicle's unassembled state, or by electrical items. Care should be taken in unpacking and assembly of the vehicle. Children should not handle parts, including the battery, or help in assembly of the vehicle. -
Page 10: Bottom View
ASSEMBLY Hole Steering Column Bottom View • Wipe the steering column with a paper towel to remove any excess lubricant. • Turn the vehicle on its side. • Before applying the labels, wipe the surface of the vehicle with a •... -
Page 11: Front View
ASSEMBLY Lens Guard Wide Tab #8 Lock Nut Lens End of Steering Column Lens Wide Notch " Screw #8 x Lens Guard • Fit the wide notch in the side of a headlight lens under the wide tab on a lens guard. •... - Page 12 ASSEMBLY Windshield Hood Latch Wipers Slot Large Large Large Slots Hood Latch Slot • Position the windshield so that the wipers face the front end of the vehicle. • Insert a hood latch into one of the slots in the front end of the vehicle.
- Page 13 ASSEMBLY Spacers Short Seat Belt Strap T-Loop (Pull through slot) Fastener End T-Loops Slot Seat Grille Slot • Turn the seat upside down. • Insert the fastener end of a short seat belt strap through the slot near the outer edge of the seat. Make sure the side of the seat belt Brush Guard with the fastener faces the outer edge of the seat.
- Page 14 ASSEMBLY Seat Sport Bar Seat Back Tabs Tabs PUSH HERE Slot Supports Side View • With the seat at an angle, insert the tabs on the front edge of the seat into the slots in the foot-well wall • Push down firmly on the edge of the seat above each tab to snap the tabs into the slots •...
-
Page 15: Back View
ASSEMBLY Taillight Sport Bar Support Housing PUSH HERE Side Fender Taillight Lens PULL HERE #8 x 1" Screws Back View • Turn the vehicle upright. • Using safety scissors, remove the taillight lenses and the taillight • Fit the sport bar assembly into the holes in the top side of housings from the plastic connectors. -
Page 16: Battery Safety Information
ASSEMBLY Loosen These Door Screws Battery Compartment Door • Locate the FM Radio/Simulated CD Player on the dash. • Loosen both screws in the battery compartment door. • Remove the battery compartment door. • Remove the exhausted batteries and throw them away. •... -
Page 17: Rear View
TABLE OF CONTENTS DECORATION Proper label application will help to keep the labels looking their best! When applying labels, keep the following guidelines in mind: • Wash your hands before applying the labels. • Before applying the labels, wipe the surface of the vehicle with a clean, dry cloth to remove any dust or oils. •... -
Page 18: Front Left Side
DECORATION FRONT LEFT SIDE FRONT RIGHT SIDE H3427pr-0920 H3427pr-0920... -
Page 19: H Battery Installation
BATTERY INSTALLATION IMPORTANT! Use only a Power Wheels 12 volt battery. Use of ® any other battery will damage your vehicle. Make sure that you charge the battery for at least 18 hours using the enclosed Power Wheels ® 12 volt charger before operating your vehicle for the first Motor Harness time. -
Page 20: I Battery Care And Disposal
BATTERY CARE AND DISPOSAL Care Disposal If a battery leak develops, avoid contact with the leaking acid and • Your Power Wheels ® battery is sealed lead-acid battery. They must place the damaged battery in a plastic bag. See information below be recycled or disposed of in an environmentally sound manner. -
Page 21: J Safe Driving Rules
SAFE DRIVING RULES Teach Safety Rules to Children RIDING HAZARD While children can quickly develop the skill necessary to drive this vehicle, it is important to remember that their judgment skills are still WARNING very immature. Unsupervised driving by children can lead to serious injury. -
Page 22: K Vehicle Operation
VEHICLE OPERATION IMPORTANT! Use this vehicle ONLY outdoors. Most interior floor- ing can be damaged by riding this vehicle indoors. Fisher-Price ® will not be responsible for damage to the floor if the vehicle is used indoors. Beginner Use - Low Speed Drive •... -
Page 23: L Fm Radio/Simulated Cd/Digital Clock Use
FM RADIO/SIMULATED CD PLAYER/ DIGITAL CLOCK USE FM Radio Station/ Time Display Volume Scan Reset Power Scan Eject Minute Adjust Hour Adjust Track Track Simulated Main Back Forward Reset Power/Volume • Press the power button to turn on or off. •... -
Page 24: Mvehicle Care
VEHICLE CARE BUMPER-TO-BUMPER* LIMITED WARRANTY • Check all screws, cap nuts and their protective coverings regularly and tighten as required. Check plastic parts on a regular basis for cracks or broken pieces. *One year limited warranty from the date of •... -
Page 25: Pproblems And Solutions Guide
PROBLEMS AND SOLUTIONS GUIDE IMPORTANT! If you experience a problem with your vehicle, first check the Problems and Solutions Guide below. If you still experience a problem, please contact Power Wheels Consumer Relations, toll-free at 1-800-348-0751 between 8 AM and 6 PM (EST) Monday through ®... - Page 26 PROBLEMS AND SOLUTIONS GUIDE PROBLEM POSSIBLE CAUSE SOLUTION Vehicle was running but Loose wires or loose connectors Check all wires and connectors. Make sure the suddenly stopped motor harness connector is tightly plugged into the battery, and that there are no loose wires around the motors. Tripped thermal fuse The built-in thermal fuse may "trip"...
- Page 27 PROBLEMS AND SOLUTIONS GUIDE PROBLEM POSSIBLE CAUSE SOLUTION Vehicle runs sluggishly Undercharged battery Charge the battery. A new battery should have been charged for at least 18 hours before using the vehicle for the first time. After first-time use, recharge the battery for at least 14 hours after each use.
- Page 28 PROBLEMS AND SOLUTIONS GUIDE PROBLEM POSSIBLE CAUSE SOLUTION FM Radio does not function at all Simulated CD is inserted Press the eject button to switch back to FM radio use. Power is off Power automatically turns off after about one hour of non-use. Press the power button to turn it back on.
- Page 29 Power Wheels Authorized Service Center. For the location nearest you, visit us on-line at www.powerwheels.com. Fisher-Price, Inc., a subsidiary of Mattel, Inc., East Aurora, New York 14052 U.S.A. ©2005 Mattel, Inc. All Rights Reserved. ® and ™ designate U.S. trademarks of Mattel, Inc.
