- Page 1 DATA LOGGER GEOLOGGER G8 PLUS CONFIGURATION & WIRING OF PERIPHERALS...
-
Page 2: Table Of Contents
CONTENTS DESCRIPTION PAGE Main components G8 Module Connections G8 Module Connections (bottom side) G8 Module connections (top side) Mains powered schematic wiring diagram SmartMux ID setup Rebooting a SmartMux Digital SmartMux overview Analogue SmartMux inputs Wiring options to analogue SmartMux Grounding the VW sensor shield wire to analogue SmartMux Grounding the G8 and/or Remote SmartMux G8 to analogue SmartMux system configurations... -
Page 3: Main Components
Main Components Central processing unit (CPU) – G8 Module to which all the components are linked. SmartMux (Analogue / Digital): A smart relay mechanism controlled by the CPU to switch between multiple sensors so that they can be monitored by a single CPU. -
Page 4: G8 Module Connections
G8 Module Connections SD CARD SLOT FOR DATA BACKUP RS485b DIGITAL FOR RADIO 2X OPTIONAL 2X OPTIONAL G8 RS485a DIGITAL DEVICE TO G8 INTEGRATED DEVICE TO G8 TO DEVICE DEVICE TO G8 ALERT INPUTS POWER OUTPUTS INPUT / OUTPUT INPUT / OUTPUT SYSTEMS ONLY LAN PORT FOR NETWORK TO G8 DIRECT CONNECTION OR G8 TO... -
Page 5: G8 Module Connections (Bottom Side)
G8 Module Connections (bottom side) Radio +5V/ +12V A separate module is required for radio outputs RS485a (#1) RS485b (#1) +12V +12V +12V [1] 120Ω Termination Resistor Siren Digital Sensor Horn Digital Bus [2] Not used - always have DOWN Power OUT Analogue Mux Light... -
Page 6: G8 Module Connections (Top Side)
G8 Module Connections (top side) USB Port for data backup Analogue Input 0 Trigger 0-10V | 0-3V | 4-20mA | COM Pulse Counter SGLC mv/V???? Channel can receive single ended voltage signal... -
Page 7: Mains Powered Schematic Wiring Diagram
Mains Powered G8 Enclosure Schematic Wiring Diagram Radio 240V - 12V Battery Transformer Modem G8 Module SmartMux filter MAINS IN SENSORS IN... -
Page 8: Smartmux Id Setup
SmartMux ID Setup SmartMux IDs are determined by the use of mini dipswitches at the front of each unit. These are usually preconfigured before you receive them, according to your system design. MUX ID 20 MUX ID 1 The setup is based on zero index binary, with the least significate bit at the front. -
Page 9: Rebooting A Smartmux
Rebooting a SmartMux Reboot Mode Rebooting the SmartMux will cause it to lose it’s memory and it will then be able to communicate with a new G8 In the middle block of dipswitches, push all 1-8 up 2. Supply power to the mux. The easiest way to do this is by creating a local reading of that mux (any channel) A SmartMux will memorise the name of the first G8 it communicates with and will only communicate with... -
Page 10: Digital Smartmux Overview
Incorporating a Digital SmartMux (DMUX) with Analogue SmartMuxs (GMUX) Channel 1 Channel 1 Channel 1 Channel 2 Channel 2 Channel 2 GMUX ID0003 Channel 3 Channel 3 Channel 3 Channel 4 Channel 4 Channel 4 Channel 5 Channel 5 Channel 5 Channel 6 Channel 6 Channel 6... -
Page 11: Analogue Smartmux Inputs
Analogue Smart Mux inputs mV/V Sensors 4-20mA Sensors VW +Temp Sensors BOTTOM G8 RS485a/b RS232 (For Radio Module) +V In GND EXTERNAL POWER SUPPLY... -
Page 12: Wiring Options To Analogue Smartmux
Wiring Options to Analogue Smart Mux Channel 13 Sensor Channel 14 Sensor Channel 15 Sensor Channel 16 Sensor 4-20mA output Uniaxial Tilt x2 No temperature Channel 9 Sensor Channel 10 Sensor Channel 11 Sensor Channel 12 Sensor 4-20mA output Biaxial Tilt No temperature Channel 5 Sensor Channel 6 Sensor... -
Page 13: Grounding The Vw Sensor Shield Wire To Analogue Smartmux
Grounding the VW Sensor Shield Wires to the Analogue Smart Mux Reduce the effects of electronic interference by grounding the sensor cables to the GND ports on the right side of the mux 1 2 3 4 1 2 3 4 1 2 3 4 1 2 3 4 1 2 3 4 5 6 7 8... -
Page 14: Grounding The G8 And/Or Remote Smartmux
Grounding the G8 and/or Remote SmartMux The return of the battery BATTERY provides the ground Common ground connects any mux to the G8 Twisted pair provides A & B Mains power has it’s own earth cable signals whilst cancelling out noise. -
Page 15: G8 To Analogue Smartmux System Configurations
G8 to Analogue Smart Mux System Configurations 1. Mux - G8 - Mux - Mux……(n) Mux Mux at the end RESISTOR Mux at the end RESISTOR G8 within the string, not at of the string of the string the beginning or end: RESISTOR ON RESISTOR ON RESISTOR OFF... -
Page 16: Typical Wiring Between G8 & Analogue Smartmux (G8 At Start Of Chain)
Typical Wiring between G8 and Analogue Smart Mux Configuration G8 at the start of the chain RS485b COM B A +12V REMOTE SMARTMUX yyyyy RS485 REMOTE SMARTMUX xxxxx RS485 REMOTE SMARTMUX zzzzz RS485 Enclosure 1 Enclosure 2... -
Page 17: Typical Wiring Between G8 & Analogue Smartmux (G8 In Middle Of Chain)
Typical Wiring between G8 and Analogue Remote Smart Mux Configuration G8 in the middle of a chain RS485a RS485b COM B A +12V COM B A +12V Enclosure 1 REMOTE SMARTMUX yyyyy RS485 REMOTE SMARTMUX xxxxx REMOTE SMARTMUX zzzzz RS485 RS485 Enclosure 2 Enclosure 3... -
Page 18: G8 To Analogue Smartmux Connections (Rs232)
G8 to Analogue Smart Mux Connections (RS232) Useful if the two RS485 ports are already in use The RS232 connection on the Mux is not designed for a direct connection from the G8 to a Mux. To connect the G8 to a Mux using the RS232 ports on the G8, you must use an RS232 - RS485 converter to change an analogue signal into a digital signal. -
Page 19: Router/Modem Setup
Router/Modem Setup Parts of the standard router Mains supply: 2 pin plug provided Antenna: Required for GSM connection. The modem will not work without this, or another SMA antenna connected LAN Cable: C onnect your PC to the Modem for initial setup, and then to connect the modem to the G8 The Router... - Page 20 Router/Modem Setup Powering the router When installed in an enclosure like this, the router can be powered by the G8 itself using the MOD1/2 connectors When powered AND connected, the router lights will look like this, with the S1 light flashing...
- Page 21 Router/Modem Setup Accessing the router network To configure the router, you must directly connect to it using your PC & the LAN cable. Then you must change your PC IP to match the network of the modem 1. Using the Network and Sharing Centre, go to Configuration the properties of the Local Connection (sometimes you must go to ‘change adapter...
- Page 22 Router/Modem Setup Configuring the router Configure your PC to be on the same network as the router Using a web browser, type in Local Network the IP address stated on the Confirm the IP address label of the router of the modem Use the password stated on the Red = disconnected/no signal label...
-
Page 23: G8 As A Web Server
The G8 as a Web Server Controlling the G8 remotely (data not accessible except for local acquisitions) Geosense issued SIM Card numbers and IP addresses can be found: \\geohost1\Company-G\ADMINISTRATION\MONTHLY FEES\SIM CARDS Type the public IP address of the SIM card into the web browser, preset username = admin, password = 1234 (these can be changed within the G8 setup). -
Page 24: G8 As An Ftp Server
The G8 as an FTP Server https://filezilla-project.org/ - Download FileZilla Client Accessing the G8 files remotely Download an FTP client such as ‘Filezilla’ and connect to the G8 by inputting the host details: General: Host = SIM IP address User and Password is the same as your remote access username and password, usually ‘admin’... -
Page 25: G8 Configuration
G8 Configuration G8 Logger Setup CONFIGURATION G8 LOGGER SETUP ID NUMBER MODULES SUPPLY MODULE 1 SUPPLY ON DURING ACQ Modem or alarm PLANNED ON DAILY SWITCH ON power supply controls HOURLY SWITCH ON ALWAYS ON MODULE 2 SUPPLY AS PER MODULE 1 SUPPLY RADIO MODULE ANALOGUE INPUTS ADC0... - Page 26 CONFIGURATION G8 LOGGER SETUP SET DATE/TIME YY > MM> DD> HH > MM LAN CONFIG MANUAL LAN CONFIG This is the IP address of the logger itself DHCP SD CARD EXPLORER MUMS These are the same folders that you can see SYSTEM—>1 on an FTP Client.
- Page 27 CONFIGURATION G8 LOGGER ADVANCED TOOLS SYSTEM BACKUP DATA BACKUP SETUP BACKUP RATE USB BACKUP POWER MODE FULL FUNCTIONS MIDNIGHT RESET LOW POWER MODE MODULE 1 SUPPLY ON DURING ACQ PLANNED ON DAILY SWITCH ON HOURLY SWITCH ON ALWAYS ON MODULE 2 SUPPLY AS PER MODULE 1 SUPPLY RADIO MODULE ULTRA LOW POWER...
- Page 28 CONFIGURATION G8 LOGGER SETUP ADVANCED TOOLS ALARMS ALARM THRESHOLDS VIEW LIMIT VIEW/EDIT LIMIT DELETE LIMIT DELETE ALL LIMITS SENDER MAIL RECEIVERS MAILS NOTIFICATION LIST VIEW EDIT APPEND NEW (ERASE ALL) WARNING LIST VIEW EDIT APPEND NEW (ERASE ALL) ALARM LIST VIEW EDIT APPEND...
- Page 29 CONFIGURATION G8 LOGGER SETUP SYSTEM INFO NEW (ERASE OLD) VIEW PIN SECURITY SET/CHANGE PIN REMOVE PIN EXPERT MENU DEV EEPROM IM/EXP READ FROM DEVICE WRITE TO DEVICE DEV FW UPGRADE Test connection integrity by pinging the Google server IP PING 8.8.8.8 RADIO TOOLS RADIO NODES LIST...
- Page 30 CONFIGURATION DEVICES CONFIG MUMS CONFIGURATION VIEW MUMS NEW/EDIT MUMS RS485a RS485b RS232a RS232b WIRELESS DELETE MUMS DELETE ALL MUMS IPTM CONFIGURATION VIEW IPTM NEW/DIT IPTM RS485a RS485b RS232a RS232b WIRELESS DELETE IPTM DELETE ALL IPTM Create a new data acquisition and backup existing data files ACQUISITIONS NEW DATA ACQUISITION APPEND DATA ACQUISITION...
