ASSEMBLY GUIDE
Fixed Frame
Projector Screen
NS-SCR120FIX19W / NS-SCR100FIX19W
Before using your new product, please read these instructions to prevent any damage.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NS-SCR120FIX19W and is the answer not in the manual?

Questions and answers

Related Manuals for Insignia NS-SCR120FIX19W

Summary of Contents for Insignia NS-SCR120FIX19W

  • Page 1 ASSEMBLY GUIDE Fixed Frame Projector Screen NS-SCR120FIX19W / NS-SCR100FIX19W Before using your new product, please read these instructions to prevent any damage.

  • Page 2: Table Of Contents

    Contents IMPORTANT SAFETY INSTRUCTIONS ........2 Features .

  • Page 3: Features

    Projector Screen Features • A simple solution for your home theater needs • High-quality matte white screen supports resolutions as high as 4K Ultra HD • Rigid and durable aluminum frame keeps the screen flat and taunt • Black velvet frame gives the screen an elegant, theatrical look with a 152° viewing angle Dimensions 100 in.

  • Page 4: Package Contents

    Package contents Make sure that you have all the parts and hardware needed to assemble your new projector screen. Parts Short fiberglass tube (4) Support rod (1) Right horizontal frame piece (2) Long fiberglass tube (2) Screen fabric (1 roll) Left horizontal frame piece (2) Vertical frame piece (2) Hardware...

  • Page 5: Assembly Instructions

    Projector Screen Assembly instructions Step 1 – Assemble the frame You’ll need Joint bracket (2) Vertical frame piece (2) Left horizontal frame piece (2) Screw (24) Phillips screwdriver Right horizontal frame piece (2) Corner bracket (4) Connect a left horizontal frame piece to a right horizontal tube with a joint bracket and four screws to create a long horizontal tube.

  • Page 6: Step 2 - Assemble The Screen

    Adjust the four frame pieces to create a rectangle. The outer corners of the frame should be 90° angles. Lock the frame pieces into place using four screws for each corner. Note: If there’s a big gap between the frame pieces, adjust the tightness of the screws to reduce the gap.

  • Page 7: Step 3 - Attach The Screen To The Frame

    Projector Screen Make sure that the white side of the fabric is facing down, then place the screen flat into the frame. Step 3 – Attach the screen to the frame You’ll need Support rod (1) Spring (100 in. model: 38) (120 in.
  • Page 8 Use the installation hook to pull the large hook toward the center of the frame, then insert the large hook into the hole in the screen fabric. Repeat with all the remaining springs. Locate the springs in the middle of the top and bottom of the frame, then insert the top of the support rod into the notch groove on the spring.

  • Page 9: Step 4 - Hang Your Projector Screen

    Projector Screen Step 4 – Hang your projector screen You’ll need Pencil Phillips screwdriver Hanging bracket A (2) Hanging bracket B (2) Drill with 8 mm bit Hammer or mallet Plastic anchors (6) Bakelite screws (6) Align one of the hanging brackets A on the wall where you want to install the top of your projector screen.

  • Page 10: Maintaining Your Screen

    Hang the hanging brackets B on the bottom of the aluminum frame, then slide the brackets so they align with the A brackets. The distance between the brackets B should be the same as the distance you used for the brackets A. Note: Make sure that you attach the brackets B to the aluminum frame first, then secure the brackets to the wall.

  • Page 11: Storing Your Screen

    Projector Screen Storing your screen Remove the screen from the brackets B. If you want to roll the fabric, remove the springs. Roll the fabric into a tube to prevent damage. Do not disassemble the frame. You can damage the frame pieces. Note: To protect the screen, cover it with a piece of cloth or plastic.

  • Page 12: One-Year Limited Warranty

    Product is determined to be defective by an authorized Insignia repair center or store personnel, Insignia will (at its sole option): (1) repair the Product with new or rebuilt parts; or (2) replace the Product at no charge with new or rebuilt comparable products or parts.
  • Page 13 Projector Screen • Connection to an incorrect voltage or power supply • Attempted repair by any person not authorized by Insignia to service the Product • Products sold “as is” or “with all faults” • Consumables, including but not limited to batteries (i.e. AA, AAA, C etc.) •...
  • Page 14 1-877-467-4289 (U.S. and Canada) or 01-800-926-3000 (Mexico) INSIGNIA is a trademark of Best Buy and its affiliated companies. Distributed by Best Buy Purchasing, LLC V1 ENGLISH ©2020 Best Buy. All rights reserved. 20-0294...
