- Page 1 LILAC DESK ASSEMBLY INSTRUCTIONS Date: 2013-Jan.-30 Rev: 2013-Oct.-10 www.pbteen.com Page 1 of 5...
- Page 2 – 1x – 4x M8x50mm – 12x (G) Flat washer – 12x (H) Allen key 5mm – 1x (I) Tipping-Restraint Kits – 1set TOOLS REQUIRED (but not included): Phillips Head Screwdriver Date: 2013-Jan.-30 Rev: 2013-Oct.-10 www.pbteen.com Page 2 of 5...
- Page 3 5. Tighten all bolts with Allen key (H) but do not over-tighten, as seen in the Figure 2. 6. Repeat Step # 3- #5 to assemble the other 3 Legs (B). Fig. 2 （E） （F） （G） （H） Date: 2013-Jan.-30 Rev: 2013-Oct.-10 www.pbteen.com Page 3 of 5...
- Page 4 9. Tighten the screws with Phillips Head Screwdriver (not provided), but do not over tighten. 10. Repeat step # 7- # 9 to assemble the Large Knobs (D) to the side Drawers. Date: 2013-Jan.-30 Rev: 2013-Oct.-10 www.pbteen.com Page 4 of 5...
- Page 5 11. Slowly turn the Desk upright and place the drawers back into the desk. 12. If the desk doesn’t sit level, adjust the levelers under legs to keep the desk level. 13. As a safety precaution, please follow the separate instruction enclosed to secure the Lilac Desk to the wall using Tipping-Restraint Kits (I).
