Assembly Instructions
CM4230C
ASSEMBLY RATING
Tools Required for Assembly:
The Assembly Rating is a 5-point system that
shows the degree of effort needed in
Allen Wrench
assembling a specific product (with 1 being
(Included)
easy and 5 being difficult). For some
products, two persons are recommended.
DIFFICULT
EASY
2 PERSONS RECOMMENDED
Page 1 of 5
Rev.14-11-07
Advertisement
Related Manuals for Furniture of America CM4230C
Summary of Contents for Furniture of America CM4230C
- Page 1 Assembly Instructions CM4230C ASSEMBLY RATING Tools Required for Assembly: The Assembly Rating is a 5-point system that shows the degree of effort needed in Allen Wrench assembling a specific product (with 1 being (Included) easy and 5 being difficult). For some products, two persons are recommended.
- Page 2 Page 2 of 5...
- Page 3 Before you begin, please read Page 2 of “Assembly and Care Advice”. And remember, do not tighten until each step is completed or instructed. Parts List Hardware List #1 x 2 pcs #A x 10 pcs Leg Stand Flat Bolt 1/4”x5/8” #B x 4 pcs #2 x 1 pc Bolt 1/4”x1-1/4”...
- Page 4 Align the threaded ends of the 4 levelers (#E) with the pre-drilled holes on the 2 leg stands (#1) and tighten by hand until secured. #E x 4 pcs Turn right (clockwise) to tighten Adjust the levelers according to the ground level on Step 4.
- Page 5 Turn right (clockwise) to tighten #B x 4 pcs #D x 4 pcs Align the assembled leg stands (#1) with the pre- drilled holes on the table frame (#4). Prepare 4 bolt assemblies by inserting the flat washer (#D) onto the bolt (#B). III.
