MEGASTEK MT70 User Manual

Gps vehicle and personal location tracker
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
GPS
Vehicle and personal location tracker
_______________________________________
___
User manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MT70 and is the answer not in the manual?

Questions and answers

Related Manuals for MEGASTEK MT70

Summary of Contents for MEGASTEK MT70

  • Page 1 Vehicle and personal location tracker _______________________________________ User manual...

  • Page 2: Table Of Contents

    Contents Product overview ..............................2 2. Safety instruction ..............................3 3. Specification and parameters ..........................3 4. Getting started................................ 4 4.1 Hardware and accessories ..........................4 4.2 View ................................5 4.3 Function key and port ............................ 5 4.4 First use................................7 5.

  • Page 3: Product Overview

    1. Product overview Welcome to purchasing our product! The vehicle and personal location tracker has the advantages of low power, 15 days standby without charging, small size, easy to use and supports two-way communication. It is specially applies for elderly/kid tracking, personnel management, assert tracking, vehicle positioning, etc.

  • Page 4: Safety Instruction

    ◆Time-zone setting ◆Low battery alarm ◆LED indication for battery level ◆Auto power on/off 2. Safety instruction Read these simple guidelines. Not following them may damage to the tracker, put you in danger or break the law. Do not switch the tracker on when mobile phone use is prohibited or when Switch on safely it may cause interference or danger.

  • Page 5: Getting Started

    GPS Frequency L1, 1575.42 MHz C/A Code 1.023 MHz chip rate Channels 50 Channels Position Accuracy <10 M, 2D RMS Velocity Accuracy 0.1 M/S Time Accuracy Satellite time: 1 microsecond time synchronization Update Time Average 0.1 second Hot Start up Average 1 second Warm Start up Average 3 second...

  • Page 6: View

    4.2 View Front view Back view Side view 4.3 Function key and port GSM LED Power LED Power switch Battery checking button and Hang rope hole Speaker GPS LED SOS button Microphone Mini USB port – Power indication Always On Power charging Always OFF Power charging completed or no connection...
  • Page 7 function works well Always Off GSM in power save mode Yellow – GPS indication GPS module is initializing or waiting for the SOS 0.3S On and 0.3S Off button press to confirm the calling in number as the authorization number Always On While Pressing Button 1S On and 3S Off...

  • Page 8: First Use

    4.4 First use Please read this manual before using the tracker. 4.4.1 Ensure that your tracker has a working SIM card installed. - Tracker supports Micro SIM card and standard SIM card (please according actual situation to judge). - Check the SIM card has not run out of credit money (Test the SIM card in a phone to make sure it can send and receive SMS).

  • Page 9: Authorized Number

    6. Authorized number 6.1 Set the authorized number by SMS SMS Command: $SMS,000000;W010,NO.,Phone Number,ABC;! Description: Set authorized number and related functions. Explain: NO.: authorized number’s serial number, range of: 1~3. Phone Number: authorized number, range of: 0~19 characters. A: switch for Geo-fence function, range of: 0~1(0 means disable this function, 1 means enable this function), default is 0.

  • Page 10: Real Time Tracking

    6.5 Real time tracking The tracker will reply a location message by SMS if any authorized number makes a phone call to it. 7. SOS emergency calling Press SOS button for 3 seconds or longer, the device will send SOS alarm to all authorization numbers by SMS.

  • Page 11: Auto Apn Setting

    Auto APN setting The APN list can be configured before delivery (default is China APN). When insert SIM card, tracker will automatically acquire APN in the APN list. If user already set APN, then the tracker will not acquire APN automatically. Three kinds of tracking mode SMS Command: $SMS,000000;W016,X;!

  • Page 12: Time Zone Setting

    （Note: according to Preset longitude and latitude as the center of the circle, with the preset radius, we can define a circle.） Example: $SMS,000000;W018,1,school,22.12345,114.12345,100;! $SMS,000000;W018,1,home,,,100;! Time zone setting SMS Command：$SMS,000000;W020,X;! Description: Set the SMS time zone Explain: X: time zone’s value, range of:-720~780, default: 0, unit：minutes. (Example: 1 hour = 60 minutes, time zone+ 8 = 480 minutes) For example: $SMS,000000;W020,480;!

  • Page 13: App For Smart Phone

    APP for smart phone a) Software of setup by smart phone b）Software of tracking by smart phone Only for android system Support android & iOS system GPS tracking and monitoring platform UserName: Guest Password: 666666 Website: http://hk.gpstotrack.com/gps...

  • Page 14: Problems & Diagnostics

    Problems & Diagnostics Cannot Switch On Possibility Solution Power switch operation’s problem Slide to the ON side Low battery Charging for 2.5 – 3 hours Not Sending SMS Possibility Solution Make sure tracker can receive the strong GSM signal Blue LED always On Check SIM card installation, insert again if necessary Replace a new SIM if necessary Wait for SMS.
  • Page 15 GSM signal is weak Move the tracker to a place with strong GSM signal...
