- Page 1 Quick Installation Guide TFC-1000MSC(D1)
- Page 2 Table of Contents 1 English 1. Before You Start 2. Hardware Installation 3. LEDs and DIP Switches...
- Page 3 1. Before You Start Package Contents TFC-1000MSC Ÿ Quick Installation Guide Ÿ Power Adapter (5V DC, 1A) Ÿ Environmental Requirements Operating Temperature: 0 – 40 °C (32 – 104 °F) Ÿ Storage Temperature: -25 – 70 °C (-13 – 158 °F) Ÿ...
- Page 4 2. Hardware Installation Installing Two Stand Alone TFC-1000MSC Fiber Converters 1. Connect a network cable from a Gigabit port of the TFC-1000MSC to a Gigabit port on your switch (e.g. TEG-S24Dg, TEG-S16Dg). Converter 1 Converter 2 2. Connect the two fiber converters with a fiber cable. Note: The TX cable of one fiber converter must be plugged into the RX port of the second converter.
- Page 5 3. Supply power by connecting the included adapter to the back of each fiber converter and plug into an outlet. Installing a TFC-1000MSC in a TFC-1600 Chassis 1. Unscrew the bay cover from the desired bay on the chassis. 2. Remove the TFC-1000MSC by unscrewing the thumbscrew and pulling the unit away from the metal casing.
- Page 6 3. Slide the Fiber Converter into an available slot and fasten the thumbscrew. 4. Connect a network cable from the Gigabit port of the fiber converter to a Gigabit port on your switch. From here, you can connect to another fiber converter or any device with a Gigabit port and fiber port.
- Page 7 Dip Switches Function Action Switch LLCF Enable LLCF Disable Fiber Forced Mode Fiber Auto-Negotiation Note: 1. DIP switch settings can be changed at any time. Users can either (1) unplug the power supply, change the DIP switch settings, and plug in the power supply;...
- Page 8 Intelligent 1000Base-T to 1000Base-SX Multi-Mode SC Fiber Converter TRENDnet Trade Name: TRENDnet hereby declares that the product is in compliance with the essential requirements and other relevant provisions under our sole responsibility. EN 60950-1: 2006 + A11: 2009 + A1: 2010 + A12: 2011 + A2: 2013...
- Page 9 Product Warranty Registration If you have any questions regarding the product Please take a moment to register your installation, please contact our Technical Support. product online. Go to TRENDnet’s website at: Toll free US/Canada: 1-866-845-3673 www.trendnet.com/register Regional phone numbers available at www.trendnet.com/support...
