ASSEMBLY INSTRUCTIONS
ATTENTION: THIS PRODUCT IS NOT FOR COMMERCIAL USE
Easton 50 in. Round Marble Painted Glass
PARTS LIST
PART
MATERIAL CODE
NO.
1
TGS50SC-CS01
2
TGS50SC-CS02
3
62TGS52SGY101
4
17C17A0403001Y4
You will need the following tools:
-Phillips Screwdriver (Not included)
-Hex.Key Wrench (See Part #9)
Step 1:
Place the table top (#1) onto a non-abrasive
surface, such as a carpet, with the underside facing
up. Insert the legs (#2) into the plastic holders
attached on the underside of the table top (#1) rim.
Fasten them together by using screws (#4).
See Figure 1.
!
Do not sit or stand on this table.
!
A weighted umbrella base must be used when using an umbrella with this table.
!
Do not discard any of the packaging until you have checked that you have all the parts and
pack of fittings.
!
Keep children away during assembly. This item contains small parts which can be
swallowed by children. Children should always be under direct adult supervision while
using the product.
!
Retain the assembly instructions for future reference.
!
Please quote following FQC NO. when contacting service center.
INTENDED FOR RESIDENTIAL USE ONLY.
Dining Table with 18 in. Lazy Susan
PART
TABLE TOP
LEG
CENTER
CONNECTOR WITH RING
SCREW ST4.2*12
SERVICE CENTER TOLL FREE NO
TEL: 1-877-539-7436
FAX: 1-877-539-7439
SGS210B
5
17C01A0706002Y4
Q'TY
1
6
17FA05040301-Y4
4
7
1
8
9
17KAA0201----Y4
4
FIGURE 1
PAGE 1 OF 2
BOLT M6*16
WASHER d6.5*D13*1.0
18000337002
BOLT CAP M6
XGZ0070
LAZY SUSAN
HEX.KEY WRENCH 6MM
1
COURTYARD CREATIONS INC.
8
8
8
1
1
4
