Jumper Placements and
Terminal Connections
(continued)
Technical Manuals Online! - http://www.tech-man.com
8. When 565-558 Earth Detect Module is not used, and on non-isolated
systems, install an 12 AWG copper wire from TB2-3 on the 565-367 and
565-488 power supply to 0V on the battery block of the host FACP.
9. Apply system power.
10. If using internal batteries, connect as indicated.
11. If using external batteries from FACP, connect as indicated.
12. Test the system.
