L e g a c y P o w e r M e t e r S p i d e r I n s p e c t i o n S e r v i c e
L e g a c y B a t t e r y C o m p a r t m e n t E x p l o d e d V i e w
Battery compartment lid
CR2032 coin cell battery
Battery compartment screw assembly
Battery compartment
Battery compartment hole
P a r t s , T o o l s , a n d S u p p l i e s
Parts
• CR2032 coin cell battery
Safety and Protection Supplies
• Apron
• Clean, lint-free rags
• Isopropyl alcohol
• Nitrile gloves
• Safety glasses
Clocking pin hole
Clocking pin
O-ring
Spider
Lubricants and Fluids
• SRAM® Butter grease
Common Tools
• 2 mm hex wrench
• 2 mm hex bit socket
• Flat blade screwdriver
• T10 TORX® wrench
• T10 TORX bit socket
• Torque wrench

Legacy Power Meter Spider Inspection Service
