- Page 1 ThermoDesk ELECTRA™ ThermoDesk ELLURE Adjustable-Height Desk System Adjustable-Height Desk System Installation Manual INSTALLATION MANUAL Version 1.0 VERSION 2.0...
-
Page 2: Before You Begin
BEFORE YOU BEGIN PROVIDED: (19) M6 hexagonal (10) 5x20 mm (4) Foot Caps machine bolts Machine Screws (2) Support Arms (2) Hex Wrenches (2) Feet Right and Left Identical (2) Crossbars (1) Crank Shaft (1) Crank Handle Identical (2) Lifting Legs (1) Drive Shaft (1) ELLURE table top Right and Left... - Page 3 ASSEMBLY INSTRUCTIONS FOR THIS STEP: PREPARE FOR ASSEMBLY CLEAR a good-sized area to lay out all components and assemble the desk. Lay the table top down on the floor, laminate side down. If not on carpet, we recommend placing a soft blanket down first in order to protect the table top surface.
- Page 4 ATTACH ARMS TO LEGS FOR THIS STEP: ATTACH the left and right top arms to their respective lifting columns using four (4) M6 machine bolts for each top arm. Make sure the top support arms are facing outwards. Do not tighten these bolts all the way. FOR THIS STEP: INSERT DRIVE SHAFT INSERT the two rods into the drive shaft.
- Page 5 FOR THIS STEP: ATTACH BASE TO TABLE TOP EXTEND the base to the appropriate width, so that the holes in the base are aligned with the recessed nuts on the table top. Secure the base to the table top with the appropriate machine screws.
- Page 6 ATTACH FOOT CAPS FOR THIS STEP: ATTACH a foot cap to the end of each foot. FINISHED! FOR THIS STEP: FLIP the Desk upright, and insert the crank handle into the crank shaft. handle folds out of crank...
-
Page 7: Troubleshooting
replacement. -
Page 8: Specifications
AVAILABLE SIZES: Ergonomically-contoured “comfort edge” EDGING: SURFACE RATING: Ultra-durable Made in Michigan, USA MANUFACTURING ORIGIN: AVAILABLE OPTIONS FROM iMovR Stowaway Ergonomic Keyboard Tray Single and Dual-Arm LCD Monitor Stands Grommet-mounted Dual-AC Power Socket iMovR See www.iMovr.com/hours HOURS: (888) 208-6770 or (425) 999-3550...
