uint32_t rgb = (uint32_t) strtol((const char *) &payload[1], NULL, 16); // decode rgb data
int r = ((rgb >> 20) & 0x3FF); // 10 bits per color, so R: bits 20-29
int g = ((rgb >> 10) & 0x3FF); // G: bits 10-19
int b = rgb & 0x3FF; // B: bits 0-9
analogWrite(LED_RED, r); // write it to the LED output pins
analogWrite(LED_GREEN, g);
analogWrite(LED_BLUE, b);
} else if (payload[0] == 'R') { // the browser sends an R when the rainbow effect is enabled
rainbow = true;
} else if (payload[0] == 'N') { // the browser sends an N when the rainbow effect is disabled
rainbow = false;
}
break;
}
}
Again, most of the code is adapted from the previous examples, only the WebSocket part is new.
There are different types of WebSocket messages, but we're only interested in the text type, because the JavaScript code at the client
side sends the color data in text format, as a hexadecimal number, starting with a '#' sign.
Each color is a 10-bit number, so in total, it gives us a 30-bit number for the RGB value.
When the rainbow function is enabled, JavaScript sends an 'R' character, and when it's disabled, it sends a 'N' character.
Let's take a look at the HTML and JavaScript code as well:
HTML
<!DOCTYPE html>
<html>
<head>
<title>LED Control</title>
<link href='https://fonts.googleapis.com/css?family=Roboto:300' rel='stylesheet' type='text/css'>
<link href='main.css' rel='stylesheet' type='text/css'>
<link rel="apple-touch-icon" sizes="180x180" href="/apple-touch-icon-180x180.png">
<link rel="icon" type="image/png" sizes="144x144" href="/favicon-144x144.png">
<link rel="icon" type="image/png" sizes="48x48" href="/favicon.ico">
<link rel="manifest" href="/manifest.json">
<meta name="theme-color" content="#00878f">
<meta content='width=device-width, initial-scale=1.0, maximum-scale=1.0, user-scalable=0' name='viewport'>
<script src="WebSocket.js" type="text/javascript"></script>
</head>
<body>
<center>
<header>
<h1>LED Control</h1>
</header>
<div>
<table>
<tr>
<td style="width:14.4px; text-align: right">R: </td>
<td><input class="enabled" id="r" type="range" min="0" max="1023" step="1" oninput="sendRGB();" value="0"></td>
</tr>
<tr>
<td style="width:14.4px; text-align: right">G: </td>
<td><input class="enabled" id="g" type="range" min="0" max="1023" step="1" oninput="sendRGB();" value="0"></td>
</tr>
<tr>
<td style="width:14.4px; text-align: right">B: </td>
<td><input class="enabled" id="b" type="range" min="0" max="1023" step="1" oninput="sendRGB();" value="0"></td>
</tr>
</table>
<p style="margin:8px 0px">
<button id="rainbow" class="button" style="background-color:#999" onclick="rainbowEffect();">Rainbow</button>
</p>
</div>
</center>
</body>
</html>
There's really not much to it, just 3 sliders and a button linked to JavaScript functions.
JavaScript
var rainbowEnable = false;
var connection = new WebSocket('ws://' + location.hostname + ':81/', ['arduino']);
connection.onopen = function () {
connection.send('Connect ' + new Date());
};
connection.onerror = function (error) {
console.log('WebSocket Error ', error);
};
connection.onmessage = function (e) {
console.log('Server: ', e.data);
};
connection.onclose = function () {
console.log('WebSocket connection closed');
};
function sendRGB () {
var r = document.getElementById('r').value** 2 / 1023;
var g = document.getElementById('g').value** 2 / 1023;
var b = document.getElementById('b').value** 2 / 1023;
var rgb = r << 20 | g << 10 | b;
var rgbstr = '#' + rgb.toString(16);
console.log('RGB: ' + rgbstr);
connection.send(rgbstr);
}
function rainbowEffect () {
rainbowEnable = ! rainbowEnable;
if (rainbowEnable) {
